I-BOLL

+ 95°C

10 BAR

(accumulo)

3 BAR

(inerziale)

+ 110°C

12 BAR

Scheda tecnica

Bollitori vetrificati con accumulo tecnico integrato per produzione e

accumulo di acqua calda sanitaria

Glasslined cylinder with integrated buffer tank for production and storage of

domestic hot water

ENERGY

CAP.

CAP. VS CAP. ACC. HEAT EXCHANGER

Ø

H

QR

MODEL

I-BOLL 300

I-BOLL 500

CODE

LABEL

L

L

L

m

2

A3K0L51 PGP40

B

401

269

132

3.4

A3K0L55 PGP40

C

610

460

150

5.5

L

mm

mm

mm

Qr: quota di ribaltamento / Pm: pivot measurement

I-BOLL Quote connessioni (mm)

I-BOLL Connection heights (mm)

MODEL

I-BOLL 300

I-BOLL 500

DN1

DN2

DN3

DN4

DN6

DN7

DN8

DN9

DN11

DN14

DN15

DN24

DN25

DN26

DN27

20

650

33

750

1970

2075

2280

2405

1650

825

795

1695

1530

885

1915

870

840

1990

1770

930

915

1695

960

1990

780

265

345

345

825

270

380

380

235

345

235

230

380

230

I-BOLL Attacchi connessioni

I-BOLL Connection sizes

MODEL

I-BOLL 300

I-BOLL 500

ANODE

ø x ø conn. x L

32 x G11⁄4” x 520

32 x G11⁄4” x 700

DN1 DN2 DN3 DN4 DN5

G11⁄4” G11⁄4” G1” G1” G11⁄4”

G11⁄4” G11⁄4” G1” G1” G11⁄4”

DN6 DN7

G3⁄4” G2”

G3⁄4” G2”

DN8 DN9

G1⁄2” G1⁄2”

G1⁄2” G1⁄2”

DN10 DN11

G11⁄4” G1⁄2”

G11⁄4” G1⁄2”

DN14 DN15

DN24 DN25

DN26 DN27

G1” G1”

G1” G1”

G11⁄2” G1⁄2” G1”

G11⁄2” G1⁄2” G1”

G1”

G1”

Bollitore monoserpentino per PDC / Mono-tube cylinder for heat pumps

Serbatoio inerziale / Buffer tank

I-BOLL Disegni tecnici

I-BOLL Technical drawings

I-BOLL 300 - 500

Ø

DN5 DN10

DN4

DN6

DN1

DN2

DN3

DN15

DN26

DN27

H

DN9

DN8

DN7

DN11

DN24

DN25

DN14
