Valves

Valves

BOACHEM-ZXAB/ZYAB

PN

DN

T [°C]

m, e, p

Bellows-type globe valves to ANSI/ASME

ECOLINE GLB 150-600

27

m, e

Class

NPS [inch]

T [°C]

150 - 600

2 - 12

≥ 0 - ≤ +427

150 - 800

1⁄2 - 2

≥ 0 - ≤ +427

Description

Globe valve to ANSI/ASME with flanged ends, cast steel/stainless steel body, trim

and bellows made of stainless steel, with bolted bonnet, outside screw and yoke,

sealed by graphite gland packing and metal bellows, stainless steel/graphite

gaskets.

Applications

Petrochemical plants, chemical plants, power stations, process engineering and

general industrial applications; for thermal oil, steam, toxic and volatile fluids.

Other fluids on request.

http://shop.ksb.com/catalog/k0/en/product/ES000901

Description

Globe valve to ANSI/ASME with threaded sockets (NPT) or socket weld ends (SW),

cast steel/stainless steel body, trim and bellows made of stainless steel, outside

screw and yoke, sealed by graphite gland packing and metal bellows, stainless

steel/graphite gaskets.

Applications

Petrochemical plants, chemical plants, power stations, process engineering and

general industrial applications; for thermal oil, steam, toxic and volatile fluids.

Other fluids on request.

http://shop.ksb.com/catalog/k0/en/product/ES000902

ECOLINE GLB 800

Class

NPS [inch]

T [°C]

m, e

Globe valves to DIN/EN with gland packing

NORI 40 ZXL/ZXS

m

PN

DN

T [°C]

25/40

10 - 400

≥ -10 - ≤ +450

Description

Globe valve to DIN/EN with flanged ends (ZXL), butt weld ends or socket weld ends

(ZXS), with gland packing, with on/off disc or throttling plug, rotating stem, seat/

disc interface made of wear and corrosion resistant chrome steel or chrome nickel

steel.

Applications

Industrial plants, power stations, process engineering and shipbuilding. For water

and steam. Other non-aggressive fluids such as gas or oil on request.

http://shop.ksb.com/catalog/k0/en/product/ES000339

10 - 40

15 - 400

≥ -10 - ≤ +400

Description

Bellows-type globe valve to DIN/EN with flanged ends, body made of stainless

steel, with replaceable on/off disc or throttling plug.

Applications

Process engineering, industry, building services, food and beverage industries, for

aggressive fluids. Other fluids on request.

http://shop.ksb.com/catalog/k0/en/product/ES000337
