Valves
Valves
BOA-Control SAR
PN
DN
T [°C]
m
Level control valves to DIN/EN
CONDA-VLC
33
PN
DN
T [°C]
16
25 - 300
≥ -10 - ≤ +70
Description
Float valve to DIN/EN for controlling maximum and minimum liquid levels in tanks,
with flanged ends (DN 40-300) or threaded ends (DN 25-32), body made of nodular
cast iron; valve disc, stem, float and seat made of stainless steel.
Applications
Water supply systems, industry and building services. For controlling water levels.
http://shop.ksb.com/catalog/k0/en/product/ES000835
Pressure reducing valves to DIN/EN
CONDA-VRC
PN
DN
T [°C]
16/25/40/63
15 - 150
≥ -10 - ≤ +70
Description
Direct-acting pressure reducing valve to DIN/EN with flanged ends (DN 50-150) or
threaded ends (DN 15-50), body made of nodular cast iron; valve disc, stem and
seat made of stainless steel.
Applications
In water supply systems for controlling downstream pressure, in fire-fighting
systems for reducing excess pressure caused by pumps, in irrigation systems,
industry and building services as an efficient protection against water hammer.
http://shop.ksb.com/catalog/k0/en/product/ES000834
Pressure sustaining valves to DIN/EN
CONDA-VSM
PN
DN
T [°C]
16/25/40
50 - 150
≥ -10 - ≤ +70
Description
Direct-acting pressure sustaining valve to DIN/EN with flanged ends, body made of
nodular cast iron, valve disc, stem and seat made of stainless steel.
Applications
Controlling upstream pressure in water supply systems, irrigation systems or fire-
fighting systems, in industry and building services.
16
10 - 50
≥ -25 - ≤ +150
Description
Balancing valve to DIN/EN with female screwed ends; differential pressure
measurement for flow metering with PFM 2000 measuring computer; digital travel
position indicator with 40 settings, locking device and travel stop, maintenance-
free.
Applications
Hot-water heating systems up to 150 °C. Air-conditioning systems. Other fluids on
request.
http://shop.ksb.com/catalog/k0/en/product/ES000324
http://shop.ksb.com/catalog/k0/en/product/ES000678
