Valves

Valves

ZTS

m, e, p

37

m, e

ECOLINE GTC 150-600

Class

NPS [inch]

T [°C]

m, e

ECOLINE GTF 150-600

Class

NPS [inch]

T [°C]

m, e

ECOLINE GTF 800

m, e

PN

≤ 600

Class

4500

Description

Gate valve to DIN/EN or ANSI/ASME with butt weld ends, pressure seal design,

billet-forged body, seat/disc interface made of wear and corrosion resistant

Stellite, split wedge with flexibly mounted discs for precise alignment with the

body seats.

Applications

Industrial plants, power stations, process engineering and shipbuilding. For water

and steam. Other non-aggressive fluids such as gas or oil on request.

http://shop.ksb.com/catalog/k0/en/product/ES000375

Description

Gate valve to ANSI/ASME with threaded sockets (NPT) or socket weld ends (SW),

cast steel/stainless steel body, trim and bellows made of stainless steel, bolted

bonnet, outside screw and yoke, sealed by graphite gland packing and metal

bellows, stainless steel/graphite gaskets.

Applications

Petrochemical plants, chemical plants, power stations, process engineering and

general industrial applications; for thermal oil, steam, toxic and volatile fluids.

Other fluids on request.

http://shop.ksb.com/catalog/k0/en/product/ES000903

Description

Gate valve to ANSI/ASME with flanged ends, cast steel A216 WCB, Trim 8

(Stellite/13 % chrome steel) for Class 150/300/600, Trim 5 (Stellite/Stellite) for

Class 600, with bolted bonnet, outside screw and yoke, non-rotating stem, flexible

wedge, graphite gland packing, stainless steel/graphite gaskets.

Applications

Industrial plants, power stations, process engineering, refineries, oil and marine

applications; for water, steam, gas, oil and other non-aggressive fluids.

http://shop.ksb.com/catalog/k0/en/product/ES000774

Description

Gate valve to ANSI/ASME with flanged ends, forged steel A105, Trim 8

(Stellite/13 % chrome steel), with bolted bonnet, outside screw and yoke, non-

rotating stem, single-piece wedge, graphite gland packing, stainless steel/graphite

gaskets, reduced bore.

Applications

Industrial applications, power stations, process engineering, refineries, oil and

marine applications; water, steam, gas, oil and other non-aggressive fluids.

http://shop.ksb.com/catalog/k0/en/product/ES000611

Description

Gate valve to ANSI/ASME with threaded sockets (NPT), butt weld ends (BW) or

socket weld ends (SW), Trim 8 (Stellite/13 % chrome steel), with bolted bonnet,

outside screw and yoke, single-piece wedge, graphite gland packing, stainless

steel/graphite gaskets, available in carbon steel and alloy steel.

Applications

Industrial applications, power stations, process engineering, refineries, oil and

marine applications; water, steam, gas, oil and other non-aggressive fluids.

http://shop.ksb.com/catalog/k0/en/product/ES000797

DN

NPS [inch]

T [°C]

50 - 800

2 - 32

≥ -10 - ≤ +650

Gate valves to ANSI/ASME

ECOLINE GTB 800

Class

NPS [inch]

T [°C]

150 - 800

1⁄2 - 2

≥ 0 - ≤ +427

150 - 600

2 - 24

≥ 0 - ≤ +649

150 - 600

1⁄2- 2

≥ 0 - ≤ +816

800

1⁄2- 2

≥ 0 - ≤ +593

Class

NPS [inch]

T [°C]
