Valves
Valves
NORI 40 RXL/RXS
PN
DN
T [°C]
NORI 160 RXL/RXS
41
RGS
BOACHEM-RXA
250 - 500
10 - 50
≥ -10 - ≤ +580
10 - 40
15 - 400
≥ -10 - ≤ +400
PN
DN
T [°C]
PN
DN
T [°C]
PN
DN
T [°C]
≥ -10
≥ -10
25/40
10 - 300
- ≤ +450
63 - 160
10 - 200
- ≤ +550
Description
Lift check valve to DIN/EN with flanged ends (RXL), butt weld ends or socket weld
ends (RXS), check disc with closing spring, seat/disc interface made of wear and
corrosion resistant chrome steel or chrome nickel steel.
Applications
Industrial plants, power stations, process engineering and shipbuilding. For water
and steam. Other non-aggressive fluids such as gas or oil on request.
http://shop.ksb.com/catalog/k0/en/product/ES000358
Description
Lift check valve to DIN/EN with flanged ends (RXL), butt weld ends or socket weld
ends (RXS), check disc with closing spring, seat/disc interface made of wear and
corrosion resistant 17 % chrome steel or Stellite.
Applications
Industrial plants, power stations, process engineering and shipbuilding. For water
and steam. Other non-aggressive fluids such as gas or oil on request.
http://shop.ksb.com/catalog/k0/en/product/ES000360
Description
Lift check valve to DIN/EN with butt weld or socket weld ends, Y-pattern, check
disc with closing spring, pressure seal design, Hastelloy-faced body seats.
Applications
Industrial plants, power stations, process engineering and shipbuilding. For water
and steam. Other non-aggressive fluids such as gas or oil on request.
http://shop.ksb.com/catalog/k0/en/product/ES000364
Description
Lift check valve to DIN/EN with flanged ends, body made of stainless steel, check
disc with closing spring, lapped seat/disc interface.
Applications
Process engineering, industry, building services, food and beverage industries, for
aggressive fluids. Other fluids on request.
http://shop.ksb.com/catalog/k0/en/product/ES000366
Lift check valves to ANSI/ASME
ECOLINE PTF 150-600
Class
NPS [inch]
T [°C]
150 - 600
1⁄2 - 2
≥ 0 - ≤ +816
Description
Lift check valve to ANSI/ASME with flanged ends, forged steel A105, Trim 8
(Stellite/13 % chrome steel), reduced bore, with bolted cover, spring-loaded valve
disc.
Applications
Industrial plants, power stations, process engineering, refineries, oil and marine
applications; for water, steam, gas, oil and other non-aggressive fluids.
http://shop.ksb.com/catalog/k0/en/product/ES000424
