54

Pumps

Pumps

Slurry pumps

WBC

LSA-S

LCC-M

LCC-R

TBC

Q [m

3

/h]

H [m]

p [bar]

T [°C]

Q [m

3

/h]

H [m]

p [bar]

T [°C]

Q [m

3

/h]

H [m]

p [bar]

T [°C]

Q [m

3

/h]

H [m]

p [bar]

T [°C]

Q [m

3

/h]

H [m]

p [bar]

T [°C]

≤ 16200

≤ 80

≤ 32

≥ -20 - ≤ +120

≤ 13600

≤ 90

≤ 16

≥ -20 - ≤ +120

≤ 3200

≤ 90

≤ 16

≤ +120

≤ 2560

≤ 42

≤ 16

≤ +65

≤ 18200

≤ 90

≤ 37

≥ -20 - ≤ +120

Description

Patented design with state-of-the-art hydraulic system and highly wear-

resistant materials for high-pressure applications. The pump casing is

designed to withstand maximum stresses, e.g. during pressure surges.

Applications

Ideal for the single-stage or multistage transport of ore and tailings over long

distances and for dredging.

http://shop.ksb.com/catalog/k0/en/product/ES000227

Description

Premium design white cast iron pump for long service life handling severe

slurries. The maintenance-friendly single-wall construction and heavy section

white cast iron wet end combined with the cartridge bearing assembly

provide maximum reliability, a long service life and ease of maintenance.

Applications

Ore and tailings transport, cyclone feed, dredging (dry-installed or submerged

operation) and industrial processes.

http://shop.ksb.com/catalog/k0/en/product/ES000220

Description

The wetted pump end (casing, impeller and suction plate / liner) is made of

white cast iron. Design optimised to permit easy dismantling and reassembly

for maintenance and inspection.

Applications

Reliable pump for high heads and moderately corrosive slurries. Used in mine

dewatering, ash and tailings transport and dredging.

http://shop.ksb.com/catalog/k0/en/product/ES000217

Description

Interchangeable rubber-lined or part-metal design allows adaptation of

existing pumps to new applications by simply exchanging the pump wet end.

Applications

The pumps are suitable for moderate heads, fine particles and highly

corrosive slurries.

http://shop.ksb.com/catalog/k0/en/product/ES000218

Description

Horizontal high-pressure end-suction centrifugal pump offering maximum

resistance to wear and ease of maintenance. The conventional single-wall

design transfers stress loads from the wear parts to the casing covers in high-

pressure applications. Pump components made of highly wear-resistant white

cast iron.

Applications

High-head high-flow hydrotransport of mined ore, tailings, dredged material,

for pipeline booster stations and other severe duties.

http://shop.ksb.com/catalog/k0/en/product/ES000226

Not available for worldwide sale

Factory-automated

Automation available
