62

Pumps

Pumps

Hygienic pumps

Vitachrom

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

KSB SuPremE, PumpDrive, PumpMeter

Vitacast

KSB SuPremE, PumpDrive, PumpMeter

Vitacast Bloc

KSB SuPremE, PumpDrive, PumpMeter

Vitaprime

KSB SuPremE, PumpDrive

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

40 - 80

≤ 58

≤ 45

≤ 10

≥ -20 - ≤ +100

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

32 - 200

≤ 540

≤ 105

≤ 10

≥ -20 - ≤ +140

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

25 - 150

≤ 340

≤ 105

≤ 10

≥ -30 - ≤ +140

Not available for worldwide sale

Factory-automated

Automation available

50 - 125

≤ 340

≤ 100

≤ 12

≥ -30 - ≤ +110

Data for 50 Hz operation

Also available for 60 Hz

Description

Service-friendly non-self-priming single-stage hygienic close-coupled pump in

back pull-out design with magnetless KSB SuPremE motor (exception: motor

sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with permanent

magnets) of efficiency class IE4/IE5 and PumpDrive variable speed system. The

pump features a semi-open impeller and electropolished surfaces. It is very

easy to clean by CIP/SIP thanks to its almost complete lack of dead volume and

narrow clearances. Its wetted components are made of 1.4404/1.4409

(AISI 316L/CF3M) stainless steel. Vitachrom is EHEDG-certified. All materials

comply with FDA standards and EN 1935/2004. ATEX-compliant version

available.

Applications

Hygienic handling of fluids in the food, beverage and pharmaceutical

industries as well as in the chemical industry.

http://shop.ksb.com/catalog/k0/en/product/ES000030

Description

Service-friendly volute casing pump with magnetless KSB SuPremE motor

(exception: motor sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with

permanent magnets) of efficiency class IE4/IE5 and PumpDrive variable speed

system. All wetted components are made of 1.4404/1.4409 (AISI 316L/CF3M)

stainless steel. Designed with very little dead volume; open impeller,

electropolished surface, excellent efficiency. Hygienic design for the highest

requirements on cleanability (CIP/SIP-compatible), certified by the TNO

Nutrition and Food Research Institute to EHEDG standards. All materials

comply with FDA standards and EN 1935/2004. ATEX-compliant version

available.

Applications

Hygienic handling of fluids in the food, beverage and pharmaceutical

industries as well as in the chemical industry.

http://shop.ksb.com/catalog/k0/en/product/ES000785

Description

Service-friendly volute casing pump with magnetless KSB SuPremE motor

(exception: motor sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with

permanent magnets) of efficiency class IE4/IE5 and PumpDrive variable speed

system. All wetted components are made of 1.4404/1.4409 (AISI 316L/CF3M)

stainless steel. Designed with very little dead volume; open impeller,

electropolished surface, excellent efficiency. Hygienic design for the highest

requirements on cleanability (CIP/SIP-compatible), certified by the TNO

Nutrition and Food Research Institute to EHEDG standards. All materials

comply with FDA standards and EN 1935/2004. Trolley available among other

accessories. ATEX-compliant version available.

Applications

Hygienic handling of fluids in the food, beverage and pharmaceutical

industries as well as in the chemical industry.

http://shop.ksb.com/catalog/k0/en/product/ES000785

Description

Service-friendly close-coupled side-channel pump (self-priming) with

magnetless KSB SuPremE motor (exception: motor sizes 0.55 kW / 0.75 kW

with 1500 rpm are designed with permanent magnets) of efficiency class IE4/

IE5 and PumpDrive variable speed system. All wetted components are made

of 1.4404/1.4409 (AISI 316L/CF3M) stainless steel. Hygienic design for the

highest cleanability requirements (CIP/SIP-compatible). All materials comply

with FDA standards and EN 1935/2004. Trolley available among other

accessories. ATEX-compliant version available.

Applications

Hygienic handling of fluids in the food, beverage and pharmaceutical

industries as well as in the chemical industry.

http://shop.ksb.com/catalog/k0/en/product/ES000787

Data for 50 Hz operation

Also available for 60 Hz

Other ratings possible on request

Data for 50 Hz operation

Also available for 60 Hz

Other ratings possible on request

Data for 50 Hz operation

Also available for 60 Hz

Other ratings possible on request
