Pumps

Pumps

SEZ

SEZT

PHZ

PNZ

SNW

65

Q [m

3

/h]

H [m]

T [°C]

n [rpm]

≤ 65000

≤ 33

≤ +40

≤ 990

Description

Vertical tubular casing pump with open mixed flow impeller, pump intake

with inlet nozzle or suction elbow, pull-out design available, discharge nozzle

arranged above- or underfloor, flanges to DIN or ANSI standards available.

Applications

Pumping raw water, pure water, service water and cooling water in industry,

water supply systems, power stations and seawater desalination plants.

http://shop.ksb.com/catalog/k0/en/product/ES000173

Description

Vertical tubular casing pump with open or closed mixed flow impeller

Applications

Handling seawater in seawater desalination plants.

http://shop.ksb.com/catalog/k0/en/product/ES000174

Description

Vertical tubular casing pump with mixed flow propeller, pump intake with

inlet nozzle or suction elbow, pull-out design available, discharge nozzle

arranged above- or underfloor, flanges to DIN or ANSI standards available.

Applications

Raw water, pure water, service water and cooling water in industry, water

supply systems, power stations and seawater desalination plants.

http://shop.ksb.com/catalog/k0/en/product/ES000158

Description

Vertical tubular casing pump with axial propeller, pump intake with inlet

nozzle or suction elbow, pull-out design available, discharge nozzle arranged

above- or underfloor, flanges to DIN or ANSI standards available.

Applications

Raw water, pure water, service water and cooling water in industry, water

supply systems, power stations and seawater desalination plants.

http://shop.ksb.com/catalog/k0/en/product/ES000160

Description

Vertical tubular casing pump with mixed flow impeller, single-stage, with

maintenance-free Residur bearings, discharge nozzle arranged above- or

underfloor.

Applications

Irrigation and drainage, stormwater pumping stations, for raw water and

pure water, water supply, cooling water.

http://shop.ksb.com/catalog/k0/en/product/ES000176

Q [m

3

/h]

H [m]

T [°C]

n [rpm]

≤ 20000

≤ 110

≤ +45

≤ 990

Q [m

3

/h]

H [m]

T [°C]

n [rpm]

≤ 65000

≤ 25

≤ +80

≤ 990

Q [m

3

/h]

H [m]

T [°C]

n [rpm]

≤ 65000

≤ 15

≤ +80

≤ 990

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

n [rpm]

350 - 800

≤ 6500

≤ 60

≤ 10

≤ +60

≤ 1500

Data for 50 Hz operation

Also available for 60 Hz

Higher ratings possible on request

Data for 50 Hz operation

Also available for 60 Hz

Higher ratings possible on request

Data for 50 Hz operation

Also available for 60 Hz

Higher ratings possible on request

Data for 50 Hz operation

Also available for 60 Hz

Higher ratings possible on request

Data for 50 Hz operation

Also available for 60 Hz

Higher ratings possible on request
