66

Pumps

Pumps

PNW

Beveron

SPY

≤ 30

≤ 27

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

n [rpm]

Data for 50 Hz operation

Also available for 60 Hz

Higher ratings possible on request

Q [m

3

/s]

H [m]

Data for 50 Hz operation

Also available for 60 Hz

Higher ratings possible on request

Description

Vertical tubular casing pump with axial propeller, single-stage, with

maintenance-free Residur bearings, discharge nozzle arranged above or

below floor level.

Applications

Irrigation and drainage, stormwater pumping stations, for raw water and

pure water, water supply, cooling water.

http://shop.ksb.com/catalog/k0/en/product/ES000163

Description

Concrete volute casing pump with mixed flow impeller, single-stage, with

zero-maintenance Residur bearings lubricated by the fluid handled.

Applications

Coast protection and flood control, irrigation and drainage, low-lift pumping

stations, reservoir filling, cooling water, raw and pure water.

http://shop.ksb.com/catalog/k0/en/product/ES000868

Description

Long-coupled volute casing pump, single-stage, in back pull-out design.

Applications

Irrigation, drainage and water supply systems, for pumping condensate,

cooling water, service water, etc.

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

n [rpm]

350 - 1200

≤ 21600

≤ 50

≤ 10

≤ +105

≤ 1480

Data for 50 Hz operation

Also available for 60 Hz

Higher ratings possible on request

Pumps for nuclear power stations

RER

RSR

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

n [rpm]

≤ 800

≤ 40000

≤ 140

≤ 175

≤ +350

≤ 1800

Description

Vertical single-stage reactor coolant pump with forged circular casing plated

on the inside, with diffuser, either with integrated pump thrust bearing or

shaft supported by motor bearing.

Applications

Reactor coolant recirculation in nuclear power stations.

http://shop.ksb.com/catalog/k0/en/product/ES000144

Description

Vertical single-stage reactor coolant pump with cast or forged casing, shaft

supported by motor bearing.

Applications

Reactor coolant recirculation in nuclear power stations.

http://shop.ksb.com/catalog/k0/en/product/ES000146

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

n [rpm]

≤ 750

≤ 24000

≤ 215

≤ 175

≤ +350

≤ 1800

Available for 50 Hz and 60 Hz

Higher ratings possible on request

Available for 50 Hz and 60 Hz

Higher ratings possible on request

Not available for worldwide sale

Factory-automated

Automation available

350 - 800

≤ 9000

≤ 10

≤ 10

≤ +60

≤ 1500
