72

Automation

Automation

Hyatronic N

Number of pumps

P [kW]

U [V]

≤ 6

22

3~400

Description

Pump control system in control cabinet for cascade starting and stopping of

up to six pumps.

Applications

For draining tanks and sumps in drainage and waste water disposal

applications. For filling tanks in water supply applications. Level measurement

using float switch or 4...20 mA sensor.

http://shop.ksb.com/catalog/k0/en/product/ES000303

Description

Protection module for water and waste water products as all-in-one device

for motor temperature measurement, bearing temperature measurement,

leakage measurement, vibration measurement and voltage measurement, as

well as diagnosing a pump, pump system or submersible mixer to ensure

trouble-free and reliable operation.

Applications

In water and waste water systems in combination with Amacan, Amamix,

Amaprop, Amaline, Amarex KRT or Sewatec

http://shop.ksb.com/catalog/k0/en/product/ES000946

Monitoring and diagnosis

Amacontrol III

Not available for worldwide sale

Available for higher ratings and other mains

voltages on request.

Connections

Fastening

T [°C]

Dimensions

H × W ×D [mm]

U [V]

U [V]

Spring-loaded

terminals

35 mm standard

rail

≥ -30 - ≤ +70

127,2 × 45 × 113,6

AC 115-230 ± 10 %

AC/DC 24 ± 10 %
