294 4.4 Outdoor drains
Modular system 200
Catalogue EN 4.1
KESSEL AG
Gutter drains
Upper section
in polymer
Cover: Cover plate Ø 218 mm
class A 15 / L 15 (1.5 to.),
surface water tight
Art. no. 67 775
Accessories
235
200
Extension section
Material: Polymer
Installation height: 150 mm
218
without lateral inlet
196
218
Art. no. 67 400
Art. no. 67 500
Art. no. 67 600
Lip seal
Art. no. 27 140
Non-slip mounting
Art. no. 27 141
136
Bell-shaped odour trap insert
Lifting mechanism
For removing odour trap in
case of deeper installation.
Compatibility: Art. no. 27 171,
67 960, 67 970
Art. no. 850 144
Vertical outlet
Drain body in polymer
without odour trap
Lateral outlet 2.5°
Ø235
210
Drainage capacity: 4.5 l/sec flow rate
Ø110
Art.no.67000
Drainage capacity: 4.5 l/sec flow rate
Ø110
Art.no.67040
H 70 mm
H 100 mm
Art. no. 27 170
Art. no. 27 171
Ø218
in polymer
Cover: Rain inlet cover Ø 218 mm
with protective pipe Ø 110
Ø 110
Ø218
Ø 110
Ø 110
Art. no. 67 750
235
200
243
in polymer
Cover: Rain inlet slotted cover Ø 218 mm,
for additional surface drainage
with protective pipe Ø 110
Extension section
Material: Polymer
Installation height: 240 mm
Extension section
Material: Polymer
Sludge basket
Material: PE-HD
Art. no. 67 300
Wall securing bracket
Art. no. 67 800
Ø235
Ø 110
210
without lateral inlet
136
Material: PP, removable
sealing water height:
with lateral inlet
Installation height: 240 mm
823
Ø 110
Ø235
Ø 200
Ø243
170
Art. no. 67 700
186
