Grease separator EasyClean free Mix & Pump NS 2 – 10

for free-standing installation

EN 1825

Tank

Manufactured from virgin, non-recycled polyethylene, for free

standing installation in frost protected areas, with integrated

sludge trap, sloped interior base improves cleaning and reduces

disposal time, inlet flow calming system and outlet flow

regulation device, inlet and outlet interchangeable, slanted twin

access covers with quick release odour tight snap closures,

inspection window with interior cleaning arm, 75 mm OD PN 10

pressure disposal pipe, with integrated fork lift grips at base of

separator, low weight - compact design, 100 % corrosion free

polyethylene body construction (20 year warranty).

Disposal System

Mix & Pump version manually controlled odour free disposal,

cleaning and refilling system at touch of button, maintenance free

macerating pump (stainless steel blades) for separator cleaning

and disposal, includes closure valve for easy pump removal, pump

floor mount included with installation hardware and anti-vibration

matt, manual hand valve for transfer from cleaning to disposal

mode, pumping capacity 3.0 kW (stronger pumps available on

request), 5 m cable length, top mounted water jet(s) for grease

layer breakup and water spray nozzles for interior wall cleaning

during disposal, 1 inch manual hand valve for water refill, 1 inch

interior threaded refill inlet with air gap.

Control Unit with LCD display control settable in English, German,

French, Italian, Dutch or Polish language and mains power safety

on/off switch, with BMS connections.

Delivery: System completely assembled.

NS

NS 2

NS 3

NS 4

NS 7

NS 10

without SonicControl

Art. no.

93 002.01/MS

93 003.01/MS

93 004.01/MS

93 007.01/MS

93010.01

l

/MS

with SonicControl

Art. no.

93 002.02/MS

93 003.02/MS

93 004.02/MS

93 007.02/MS

93 010.02/MS

420

420

420

h

2

h

2

h

2

h

1

h

3

h

1

h

3

h

1

h

3

Accessories: Sampling chamber pages 341 – 343,

lifting stations see chapter "3"

Technical note: page 340

Note: Also available in 60 Hz / 400 V

Pumping capacity

H [m]

18

16

14

12

10

8

6

4

2

l

OD 75

OD 75

OD 75

NS

2

3

4

7

10

Ø (mm)

110

110

110

160

160

a (mm)

1500

1500

1880

1910

2590

Installation dimension

l ×b (mm)

1735 × 680

1735 × 680

2115 × 680

2145 × 940

2820 × 940

b1 (mm)

860

860

860

1130

1130

h1 (mm)

985

985

985

1185

1185

h2 (mm)

1055

1055

1055

1255

1255

h3 (mm)

1435

1435

1435

1655

1655

Weight (kg)

Water and

Grease

10

20

30

40

50

60Q[m

3

/h]

a

Sludge trap (l)

b1

b

b1

3,0 kW

155

200

160

300

173

400

221

700

267

1000

grease (l)

400

300

400

650

900

storage (l)

100

120

160

280

400

Total (l)

600

600

800

1350

1900

a

l

a

b

b

b1

Ø = Outer diameter

b1 = Set-up dimensions
