KESSEL AG

Catalogue EN 4.1

5.1

Grease separators 321

Grease separator EasyClean free Auto Mix NS 15 – 50

for free-standing installation

EN 1825

Tank

Manufactured from virgin, non-recycled polyethylene, for

free-standing installation in frost-protected areas, with

integrated sludge trap and sloped base for fast and clean

disposal, with two domed covers made of polymer, with

quick-release closures, sealed odour-tight, with suction

device installed for the joint disposal of contents of sludge

trap and grease separator chamber, intake pipe 75 mm

OD PN 10 in accordance with DIN 2501, Storz-B coupling

R 2 1/2 for connection to the disposal vehicle.

2 solenoid valves 1“, inspection window with wiper, viewing

window with wiper. Inlet and outlet Ø 200 / 250 mm for

the connection to PE-HD pipes according to DIN 19537,

HT pipes according to DIN 19560, PP or AS.

Disposal System

Auto Mix with direct disposal and Shredder-Mix-System,

KESSEL Shredder-Mix-System with mixing and rinsing via jet

and conic nozzles, external pump(s), with integrated chop-

ping mechanism and closure valve, pumping capacity 3.0 kW

(stronger pumps available on request), 5 m cable length,

refill inlet in accordance with DIN 1988, R 1 connection.

NS

NS 15

NS 20

NS 25

NS 30

NS 35

NS 40

NS 50

l

without SonicControl

Art. no.

93 015.01/DSP

630

93 020.01/DSP

93 025.01/DSP

93 030.01/DSP

93 035.01/DSP

93 040.01/DSP

93 050.01/DSP

Control Unit for actuating the pump(s) and the solenoid

valves.

Delivery: System completely assembled.

a

b

b1

l

630

a

b

630

b1

↗

Accessories: Sampling chamber, remote control,

TeleControl, SonicControl level sensing system

page s341 – 343, lifting stations see chapter "3"

↗

Technical note: page 340

↗

Note: Also available in 60 Hz / 400 V

Pumping capacity

H [m]

18

16

14

12

10

8

6

4

2

3,0 kW

l

a

h

2

h

1

h

3

G

r

e

a

s

e

s

e

p

a

r

a

t

o

r

s

h

2

h

2

h

1

h

3

h

1

h

3

NS

15

20

25

30

35

40

50

Ø (mm) a (mm)

200

3300

200

4250

200

4500

250

4600

250

6000

250

6200

250

6200

Installation dimension

l ×b (mm)

3560 × 1350

4510 × 1350

4760 × 1350

4860 × 1350

6480 × 1500

6680 × 1600

6680 × 1800

b1 (mm)

1620

1620

1620

1620

1770

1870

2070

h1 (mm)

1130

1030

1030

1170

1130

1130

1350

h2 (mm)

1200

1100

1100

1240

1200

1200

1420

h3 (mm)

1625

1525

1525

1655

1662

1662

1882

Water and

grease (l)

2300

3050

2830

2650

4500

5000

6200

Grease

storage (l)

600

800

1000

1200

1400

1600

2240

Total (l)

5.1

3800

5050

5330

5650

8000

9000

11200

1

0

2

0

30

40

50

60 Q[m

3

/h]

b

b1

Sludge trap (l)

1500

2000

2500

3000

3500

4000

5000

Illustration shows NS 20

Ø = Outer diameter

b1 = Set-up dimensions
