336 5.1 Grease separators

Grease separators EasyClean free Basic Direct NS 2 – 10

Catalogue EN 4.1

KESSEL AG

for free-standing installation

EN 1825

Service side ... (left/right)

Inspection window (with/without)

Refill inlet (with/without)

The separator for grease contaminated wastewater is suitable for free-

standing installation in frost protected areas and contains no metal parts

in the chamber. The separator chamber made of resistant polymer (PE)

includes an integrated sludge trap. Two odour-tight covers with quick-

release closures allow easy access for cleaning and maintenance tasks.

For odour-reducing manual disposal, with factory installed pressure pipe

suction outlet. After disposal, only approx. 3 L of residual sludge volume

remains in the tank.

Warranty for polyethylene material: 20 years

Standard: EN 1825

Connection of inlet/outlet fittings: PE-HD pipes according to DIN 19537,

HT pipes according to DIN 19560 (PP or AS piping)

Disposal connection DN(OD): 65 (75 mm) PN10

Delivery: System clompletely assembled.

Illustration shows Art. no. 94 004.32DR

Direction of flow "left"

Direction of flow "right"

Art. no.

94 002.10DR

94 004.10DR

94 007.10DR

94 010.10DR

94 002.21DR

94 004.21DR

94 007.21DR

94 010.21DR

94 002.12DR

94 004.12DR

94 007.12DR

94 010.12DR

94 002.32DR

94 004.32DR

94 007.32DR

94 010.32DR

Grease

storage (l) Total (l)

80

660

160

820

280

1370

400

1880

New

↗

Accessories: Sampling chamber page 341

↗

Technical note: page 340

a

b

b1

l

l

a

b

NS

Without accessories

NS2

NS4

NS7

NS 10

With inspection window

NS2

NS4

NS7

NS 10

With refill inlet

NS2

NS4

NS7

NS 10

Art. no.

94 002.10DL

94 004.10DL

94 007.10DL

94 010.10DL

94 002.21DL

94 004.21DL

94 007.21DL

94 010.21DL

94 002.12DL

94 004.12DL

94 007.12DL

94 010.12DL

Ø 455

Ø 455

Ø 455

a

Outer diameter

NS

Ø (mm)

2

110

4

110

7

160

10

160

b1

b1

D

N

/

O

D

h

2

h

2

D

N

/

O

D

D

N

/

O

D

h

2

D

N

/

O

D

D

N

/

O

D

h

1

h

1

h

3

h

3

D

N

/

O

D

h

1

h

3

Installation dimension

l ×b (mm)

1560 × 700

1960 × 700

1960 × 920

2610 × 920

b1 (mm)

920

905

1140

1120

h1 (mm)

985

985

1185

1185

h2 (mm)

1055

1055

1255

1255

h3 (mm)

1420

1420

1670

1670

Sludge trap (l)

200

400

700

1000

Water and

grease (l)

460

420

670

880

With inspection window and refill inlet

NS 2

NS 4

NS 7

NS 10

Weight (kg)

85

105

155

175

94 002.32DL

94 004.32DL

94 007.32DL

94 010.32DL

Ø = Outer diameter

b1 = Set-up dimensions
