Twin flap backwater valve Staufix Basic
Installation in an exposed wastewater pipe
EN 13564 Type 2
Made of polymer.
Installation area 650×300 mm
Twin flaps, self-closing, one of which
can be locked by hand as an emergency
closure.
Inlet/outlet for connection to PVC pipe
according to EN 1566-1.
Without rodent protection
(two polymer flaps)
1.1
Single flap backwater valve Staufix Basic
Installation in an exposed wastewater pipe
EN 13564 Type 1
Made of polymer
Installation area 650×300 mm
Self-closing flap, can be locked by hand
as an emergency closure.
Inlet/outlet for connection to PVC pipe
according to EN 1566-1.
↗
Conversion kits: page 46
↗
Accessories: pages 52 – 55
Without rodent protection
(one polymer flap)
Single flap backwater valve Staufix Basic
Installation in an exposed wastewater pipe
Outer diameter
Ø(mm)
Ø 110
Ø 125
Ø 160
Outer diameter
Ø(mm)
Ø 100
Ø 110
Ø 125
Ø 160
Ø 200
L×Hinmm
355 × 180+25
405 × 240+40
450 × 240+40
L×Hinmm
355 × 170
355 × 170
405 × 230
450 × 230
530 × 278
EN 13564 Type 0
Made of polymer
Installation area 650×300 mm
Self-closing flap.
Inlet/outlet for connection to PVC pipe
according to EN 1566-1.
↗
Conversion kits: page 46
↗
Accessories: pages 52 – 55
AxB
A x B
L
Outer diameter
Ø (mm)
Ø 110
Ø 125
Ø 160
Ø 200
L×H in mm
355 × 180+25
405 × 240+40
450 × 240+40
530 × 278+50
A×B in mm
205 × 155
270 × 200
270 × 200
353 × 248
Art. no.
73 100
73 125
73 150
73 200
AxB
L
Outer diameter
Ø(mm)
Ø 100
Ø 110
Ø 125
Ø 160
Ø 200
L×Hinmm
355 × 180+25
355 × 180+25
405 × 240+40
450 × 240+40
530 × 278+50
A×Binmm
205 × 155
205 × 155
270 × 200
270 × 200
353 × 248
A×Binmm
205 × 155
270 × 200
270 × 200
A×Binmm
205 × 155
205 × 155
270 × 200
270 × 200
353 × 248
L
With rodent protection
(one polymer and one stainless steel flap)
Outer diameter
Ø(mm)
Ø 110
Ø 125
Ø 160
L×Hinmm
355 × 180+25
405 × 240+40
450 × 240+40
A×Binmm
205 × 155
270 × 200
270 × 200
Art.no.
73 100R
73 125R
73 150R
Art.no.
77 100
72 100
72 125
72 150
72 200
Art.no.
72 100R
72 125R
72 150R
Art.no.
76 100
71 100
71 125
71 150
71 200
With rodent protection
(one stainless steel flap)
H
