Range code:

Brass

DZR

Red brass

Reduced Elbow - 401

Slow Bend - 401S

Code

Fitting size

A

B

C

D

E

F

ED-1020401--

15 x 12

15

12

21

20

28

26

FE-1020401--

18 x 15

18

15

24

21

34

33

GE-1020401--

22 x 15

22

15

25

21

34

25

DC-5020401--

12 x 10

12

10

20

18

28

22

EC-5020401--

15 x 10

15

10

21

19

31

30

GE-5020401--

22 x 15

22

15

25

21

34

31

HE-5020401--

28 x 15

28

15

26

21

38

34

HG-5020401--

28 x 22

28

22

26

25

38

39

Code

Fitting size

A

B

C

D

EE-5020401S-

15

15

41

19

22

GG-5020401S-

22

22

46

22

24

HH-5020401S-

28

28

53

27

26

24

25

Elbow with Air Vent - 401V

Code

Fitting size

A

B

C

D

EE-1020401V-

15

15

22

22

31

GG-1020401V-

22

22

60

25

37

Elbow with Drain Tap - 401DA

Code

Fitting size

A

B

C

D

EE-1020401DA

15

15

81

31

22

GG-1020401DA

22

22

91

37

25

HH-1020401DA

28

28

97

42

26

Code

Fitting size

A

B

C

D

E

F

G041020402DA

22 x 3/4"

22

3/4"

33

38

25

91

Obtuse Elbow - 401/0

Male Elbow with Drain Tap - 402DA

Extended Male Elbow with Back Nut - 402CB

Code

Fitting size

A

B

C

EE-1020401/O

15

15

24

21

GG-1020401/O

22

22

28

25

HH-1020401/O

28

28

30

26

Code

Fitting size

A

B

C

D

E

F

E031020402CB

15 x 1/2" x 38

15

54

38

21

34

1/2"

G041020402CB

22 x 1/2" x 38

22

59

38

25

38

1/2"

All sizes are in mm unless otherwise stated

All sizes are in mm unless otherwise stated
