Range code:

Brass

DZR

Red brass

Female Wall Plate Elbow 3 Hole - 403WL

Equal Tee - 601EQ

Code

Fitting size

A

B

C

D

E

F

E031020403WL

15 x 1/2"

15

1/2"

34

21

45

25

U031020403WL

16 x 1/2"

16

1/2"

34

21

45

25

F031020403WL

18 x 1/2"

18

1/2"

37

24

43

30

G031020403WL

22 x 1/2"

22

1/2"

38

25

47

35

H051020403WL

28 x 1"

28

1/2"

44

26

65

40

C035020403WL

10 x 1/2"

10

1/2"

34

18

38

23

D035020403WL

12 x 1/2"

12

1/2"

33

20

38

23

E035020403WL

15 x 1/2"

15

1/2"

34

21

45

25

G045020403WL

22 x 3/4"

22

3/4"

38

24

54

32

Code

Fitting size

A

B

C

D

DDD1020601EQ

12

12

29

58

20

TTT1020601EQ

14

14

31

63

21

EEE1020601EQ

15

15

31

63

21

FFF1020601EQ

18

18

33

66

24

GGG1020601EQ

22

22

36

73

25

HHH1020601EQ

28

28

42

83

26

AAA5020601EQ

6

6

22

45

15

BBB5020601EQ

8

8

25

50

17

CCC5020601EQ

10

10

28

56

18

DDD5020601EQ

12

12

29

58

20

EEE5020601EQ

15

15

31

63

21

UUU5020601EQ

16

18

32

63

22

FFF5020601EQ

18

18

33

66

24

GGG5020601EQ

22

22

36

73

26

HHH5020601EQ

28

28

42

83

26

JJJ5020601EQ

35

35

53

106

30

KKK5020601EQ

42

42

62

123

34

NNN2020601EQ

54

54

63

124

40

QQQ2020601EQ

67

67

98

196

64

RRR2020601EQ

76

76

118

240

79

Bent Tap Connector - 403SF

Code

Fitting size

A

B

C

D

E

E031020403SF

15 x 1/2"

15

1/2"

25

21

31

G031020403SF

22 x 1/2"

22

1/2"

29

25

33

G041020403SF

22 x 3/4"

22

3/4"

30

25

36

E035020403SF

15 x 1/2"

15

1/2"

25

21

31

28

29

All sizes are in mm unless otherwise stated
