Range code:
Brass
DZR
Red brass
Tee Reduced Both Ends - 601REE
Tee with Male End - 631
Code
Fitting size
A
B
C
D
E
EEG5020601-
15 x 15 x 22
15
22
25
21
70
GGH5020601--
22 x 22 x 28
22
28
26
25
82
Code
Fitting size
A
B
C
D
E
F
E3E5020631--
15 x 1/2" x 15
15
1/2"
34
21
26
48
G4G5020631--
22 x 3/4" x 22
22
3/4"
37
25
33
70
Tee with Male Branch - 615
Tee with Male and Female Ends - 645
Code
Fitting size
A
B
C
D
E
F
33E1020645--
1/2 x 1/2 x 15
15
1/2"
1/2"
21
23
25
Code
Fitting size
A
B
C
D
E
EE35020615--
15 x 1/2" x 15
15
1/2"
26
21
68
GG35020615--
22 x 1/2" x 22
22
1/2"
31
25
73
GG45020615--
22 x 3/4" x 22
22
3/4"
33
25
77
32
Tee with Female End - 684
33
Code
Fitting size
A
B
C
D
E
G3G1020684--
22 x 1/2" x 22
22
1/2"
37
36
60.5
G4G1020684--
22 x 3/4" x 22
22
3/4"
40
40
66
H5H1020684--
28 x 1" x 28
28
1"
45
26
79
E3E5020684--
15 x 1/2" x 15
15
1/2"
33
22
55
G3G5020684--
22 x 1/2" x 22
22
1/2"
37
36
60.5
Tee with Female Branch - 617
Code
Fitting size
A
B
C
D
TT31020617--
14 x 14 x 1/2"
14
1/2"
62
21
EE11020617--
15 x 15 x 1/4"
15
1/4"
63
21
EE31020617--
15 x 15 x 1/2"
15
1/2"
66
21
EE41020617--
15 x 15 x 3/4"
15
3/4"
74
21
UU41020617--
16 x 16 x 3/4"
16
3/4"
74.5
21.5
FF31020617--
18 x 18 x 1/2"
18
1/2"
72
24
FF41020617--
18 x 18 x 3/4"
18
3/4"
80
24
GG31020617--
22 x 22 x 1/2"
22
1/2"
73
25
GG51020617--
22 x 22 x 1"
22
1"
88
25
HH41020617--
28 x 28 x 3/4"
28
3/4"
80
26
DD25020617--
12 x 12 x 3/8"
12
3/8"
61
20.5
DD35020617--
12 x 12 x 1/2"
12
1/2"
67
24
EE35020617--
15 x 15 x 1/2"
15
1/2"
66
21
GG35020617--
22 x 22 x 1/2"
22
1/2"
73
25
GG45020617--
22 x 22 x 3/4"
22
3/4"
78
25
HH35020617--
28 x 28 x 1/2"
28
1/2"
77
26
HH55020617--
28 x 28 x 1"
28
1"
86
26
All sizes are in mm unless otherwise stated
All sizes are in mm unless otherwise stated
Cross - Equal - 901
Code
Fitting size
A
B
C
D
EEEE1020901-
15 x 15 x 15 x 15
15
63
32
21
GGGG1020901
22 x 22 x 22 x 22
22
74
37
25
