CONDIZIONAMENTO & AERAZIONE AIR CONDITIONING & VENTILATION

KIT AZOTO

NITROGEN KIT

Kit per la verifica di tenuta degli impianti di condizionamento in presenza d’azoto e di flussaggio durante la fase di saldatura. La fase di verifica di

tenuta,siottienemedianteil riduttoreelabomboladiazotoindotazioneoeventualmente unabombolapiùgrandedalt.5(cod.17.202).

Lospecialemanometroasettori,permettelavisualizzazione elacorrettaoperazionediutilizzodellevariepressioni.

The kit is specifically studied for verifying whether there are leakage in A/C systems having nitrogen as well as the fluxing during soldering operations.

Through the pressure reducing valve and the nitrogen bottle (both are supplied) it will be possible to verify whether there are leakages in the systems. The

special pressure gauge with a dial/sectors allows a correct operation by visualizing the different pressures. A nitrogen bottle having larger capacity 5 lt

(cod.. 17202) can be supplied.

Composto da :

• riduttorecod.17.184

• manometroasettori(cod.17.187/1)completoditubo1/4"SAE L.90cm

• bombolaazotopienada110barcod.17.200

• raccordo5/16"cod.17.526/4

• valigetta

It contains:

pressure reducer cod. 17.184 • dial/sectors pressure gauge complete with hose 1/4” SAE 90 cm

cod. 17.187/1• nitrogen bottle cod. 17.200 • fitting 5/16" cod. 17.52674• Supplied in a plastic case

PIENA

Certificabile

Versione

Version

Conf.

Unit

Cod.

Notes

17.180

Kit Azoto Nitrogen kit

1

KIT AZOTO

NITROGEN KIT

Kitcheconsente,grazieallospecialemanometroa settori,ilcontrollodelleperditeinpressione,illavaggio,il flussaggioduranteleoperazionidisaldatura,

laverificadella taraturadeipressostatielaverificaditenutadeimanometri degliimpiantidicondizionamentoerefrigerazione.

A kit that allows, thanks to the special sector pressure gauge, the control of the losses in pressure, the washing, the flushing during the welding operations,

checking the calibration of the pressure switches and the sealing verification of pressure gauges of air conditioning and refrigeration systems

Certificabile

Composto da:

• riduttore (cod.17.184)

• manometroasettori(cod.17.187/1)completoditubo1/4"SAE L.90cm

• tubo1/4"SAE L.2,5m

• bombolaazotopiena(cod.17.202/P)

• raccordo5/16"(cod.17.526/4)

It contains:

nitrogen regulation (cod. 17.184 ) • dial/sectors pressure gauge complete with hose 1/4” SAE

90 cm (cod. 17.187/1)• Flexible hose 1/4" SAE 2,5 m • full nitrogen bottle (cod. 17.202/P) •

adaptor 5/16" ( cod. 17.526/4 )

PIENA

RICARICABILE

REFILLABLE

Versione

Version

Conf.

Unit

Cod.

Notes

17.191

Kit Azoto Nitrogen kit

1

24
