4 VERTICAL USE

FRAME runner system, C3 installation set, C3 winding mechanism

The FRAME runner system can be colour-matched to your tambour doors.

At the same time, horizontal and vertical cabinets can be created in perfect design combination.

Select the appropriate runner from the design lines listed below with the “classic design” cabinet structure.

Runner system

Classic design

metallic-line

decor-line

color-line

ww

Running

track

17795501XXX*

17930161XXX

17795501XXX*

17795501XXX*

Cover

End cap

Inlet guide

Vertical

pelmet

17795601XXX 17796301XXX 17930101XXX 17930691XXX*

Vertical

pelmet

17021891XXX

17930741XXX*

17027351XXX

17027361XXX***

17930741XXX*

Assembly

profil

17930791XXX

17930791XXX

17930791XXX

17930091XXX

17021871XXX 17796301XXX 17930101XXX

17026521XXX 17796301XXX 17930101XXX

17026531XXX***

17930781XXX*

* Use of the assembly profile is necessary in order to achieve a uniform framed appearance. In addition, the assembly is made easier.

** From a cabinet height of 1300 mm, a mid-grip profile is recommended. In the configurator, a mid-grip profile is added from a height of 1301 mm,

which can be optionally deselected.

*** Solid-coloured with lacquer

52
