Recommended sales items
HANSALIVING
HANSALIGNA
HANSAACTIVEJET STYLE
6637 0000
EAN 4015474267916
0674 2103
8438 0213
€ 19,30
Chrome
€ 336,00
Chrome
EAN 4015474248601
€
Chrome
EAN 4057304005169
HANSALIGNA
0646 2083
€ 1.922,00
Chrome
EAN 4015474250239
Required sales items
HANSALIGNA
HANSA | LIVING
Other accessories
Bath/Shower
Bath and shower faucets
Single-lever
Wall mounted, DN15
• Body made of DZR brass
• protected against back-flow in domestic
use (according to DIN EN 1717)
Flow-rate at 3 bar: 20.4 / 13.2 l/min
Hot water supply: max. +90°C
Pull operated diverter
Automatic reset
• Single operating lever/handle
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
• Eccentric coupling(s) | Cover plate(s) | Silencer(s)
G1/2
• Ø 35 mm ceramic cartridge for flow and tempera-
ture control
• Non-return valve(s)
• Projection: 152 mm
• Fixed spout
• Aerator type: CASCADE® - aerated
stream | CACHÉ® - hidden aerator without
housing
Backflow prevention (EN1717): EB
DVGW: NW-6506CN0315, ABP: PA-IX 29273/IB, ACS: 16 ACC NY 205
412
Hand showers
Wall mounted
Flow-rate at 3 bar: 15 l/min
Flow-rate at 3 bar (with flow controller): 15 l/min
Hot water supply: max. +65°C
Hand shower size: 108 x 120 mm
– Hand shower: 1 shower spray
– Shower holder
– Shower hose (1500 mm)
– Anti limescale technology (easy to clean)
Bath and shower faucets
Single-lever
Floor standing (1 hole), DN15
• Body made of DZR brass
• protected against back-flow in domestic
use (according to DIN EN 1717)
Flow-rate at 3 bar: 20.4 / 13.2 l/min
Hot water supply: max. +65°C
Pull operated diverter
Automatic reset
– Hand shower
– Shower holder
– Shower hose (1250 mm)
1 shower spray:
– Intense
• Single operating lever/handle
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
Backflow prevention (EN1717): EB
• Ø 35 mm ceramic cartridge for flow and tempera-
ture control
HANSAVARIO Installation technology
5328 0100
• Non-return valve(s)
• Projection: 200 mm
• Fixed spout
• Aerator type: CASCADE® - aerated
stream | CACHÉ® - hidden aerator without
housing
98
Issue 01/2020
