HANSA | LIVING

HANSALIGNA

81149572

Chrome

EAN 4057304004711

Issue 01/2020

101

164

G 1/2

7

57

75

78

108

110

122

125

135

31

10

5

5

5

5

154

64-94

40

14

31

75

105

• Consisting of: Gasket sleeve for dry mortar-

less construction | Mounting box and cover sleeve

• Without trim kit

HANSALIVING

Bath and shower faucets

Trim Kit/Thermostatic

Wall mounted for concealed unit,

DN15

• Body made of DZR brass

• BLUECLICK for an easy, screwless trim

plate installation

• BLUESWITCH 2-way operated diverter

with volume control and stop function

• BLUETUNE alignment after installation

of +/– 3,5o

Flow-rate at 3 bar: 20.4 / 12 l/min

Hot water supply: max. +90°C

• Temperature control handle

• Flow control handle

• Safety stop against scalding at 38°C

• Thermostatic cartridge for automatic temperature

control

DVGW: DW-6509CS0197, ACS: 16 ACC LY 695

Required sales items

HANSABLUEBOX Installation technology

HANSABLUEBOX Installation technology

HANSALIVING

Bath and shower faucets

Trim Kit/Thermostatic

Wall mounted for concealed unit,

DN15

• Body made of DZR brass

• BLUECLICK for an easy, screwless trim

plate installation

• BLUESWITCH 2-way operated diverter

with volume control and stop function

• BLUETUNE alignment after installation

of +/– 3,5o

Flow-rate at 3 bar: 22.2 / 22.2 l/min

Hot water supply: max. +90°C

• Temperature control handle

• Flow control handle

• Safety stop against scalding at 38°C

• Thermostatic cartridge for automatic temperature

€ 537,00

1

5

4

control

DVGW: DW-6509CS0197, ABP: PA-IX 28853/IDD, SVGW: 1805-6755, ACS: 16 ACC LY 695

Required sales items

HANSABLUEBOX Installation technology

HANSABLUEBOX Installation technology

HANSABLUEBOX

Installation technology

Concealed unit

Wall mounted, DN15

• Body made of DZR brass

• Multifix fastening system

Installation depth: 75 - 105 mm

Hot water supply: max. +90°C

• G1/2

• Pressure plug

8000 0000

8001 0000

80000000

EAN 4015474278042

€ 76,10

Accessories: Raising kit, 15 mm, 59 914 182; Adapter, 59 914 184; Flush connector, 59 914 185;

Assembling plate, 4405 0000

• Non-return valve(s)

• Consisting of: Rosette plate frame | Soft edge

rosette | Fastening of the function unit with

screws | Sleeve

8000 0000

8001 0000

81149552

Chrome

EAN 4015474279018

€ 517,00

• Non-return valve(s)

• Consisting of: Round rosette | Fastening of the

function unit with screws | Sleeve

1

3

5

7

5

7

1

6

4

G

1

/

2

7

5

7

8

1

0

8

1

1

0

1

2

2

1

2

5

ø

1

2

4

H

A

N

S

A

L

I

G

N

A
