Shower

122

Issue 01/2020

HANSASTELA

HANSA | LIVING

Recommended sales items

• Non-return valve(s)

• Litter filter(s)

5301 0300

5303 0300

5307 0300

0519 9000

Chrome

EAN 4015474043091

57670101

Chrome

EAN 4015474139794

€

€ 237,00

HANSASTELA

Bath and shower faucets

Trim Kit/Single-lever

Rim mounted/Tiled rim assembly

(3 hole)

• Hose guide, revolving

Flow-rate at 3 bar: 13.2 l/min

Hot water supply: max. +90°C

– Hand shower

– Shower hose (1750 mm)

1 shower spray:

– Intense

• Single operating lever/handle

• Pin shape

• Hot/Cold symbols

Backflow prevention (EN1717): EB

Required sales items

HANSACOMPACT Installation technology

HANSA Installation technology

HANSACOMPACT Installation technology

HANSAFILL

156 Spouts

HANSASTELA

Shower faucets

Single-lever

Wall mounted, DN15

• Body made of DZR brass

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 18 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Pin shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

ABP: P-IX 28419/IB, ACS: 16 ACC NY 205

57319411

Chrome

EAN 4057304014628

Valid From: 01-04-2020

€ 385,00

• Ø 40 mm ceramic cartridge for flow and tempera-

ture control

•

•

•

•

Adjustable hot water stop (retrofittable)

Eccentric coupling(s) | Cover plate(s) | Silencer(s)

Ø 35 mm ceramic cartridge for flow and tempera-

ture control

Non-return valve(s)
