HANSA | LIVING

HANSARONDA

03032273

Chrome

EAN 4015474212701

Issue 01/2020

131

HANSARONDA

Washbasin faucets

Single-lever

Deck mounted (1 hole), DN15

• Body made of DZR brass

Flow-rate at 3 bar (with flow controller): 6 l/min

Hot water supply: max. +80°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Flexible inlet pipes (G3/8)

• Ø 35 mm ceramic cartridge for flow and tempera-

ture control

€ 300,00

Accessories: Cover flange, 55 x 55 mm, 6636 0000

DVGW: NW-6506CN0310, ABP: PA-IX 28930/IO, ACS: 16 ACC NY 205

HANSARONDA

Washbasin faucets

Single-lever

Deck mounted (1 hole), DN15

• Body made of DZR brass

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 13.2 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Pop-up waste with draw-rod

• Copper inlet pipes (Ø10)

• Ø 35 mm ceramic cartridge for flow and tempera-

ture control

KIWA: K6116/06, ABP: P-IX 29286/IA

HANSARONDA

Washbasin faucets

Trim Kit/Single-lever

Wall mounted for concealed unit,

DN15

Flow-rate at 3 bar (with flow controller): 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Hot/Cold symbols

Backflow prevention (EN1717): AA

• Consisting of: Square rosette | Sleeve | Operating

lever

• Projection: 186 mm

HANSAMATRIX

Installation technology

Concealed unit

Wall mounted, DN15

• Body made of DZR brass

• Multifix fastening system

• Rotating installation option

• protected against back-flow in domestic

use (according to DIN EN 1717)

Installation depth: 65 - 90 mm

Flow-rate at 3 bar: 21.6 l/min

Hot water supply: max. +90°C

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• G1/2

03012173

Chrome

EAN 4015474228504

• Non-return valve(s)

• Projection: 125 mm

• Fixed spout

• Pull-out model

€ 322,00

Accessories: Assembling plate, 4405 0000; Assembling plate, 4405 0100

• Without pop-up waste | Without draw-rod

opening

• Projection: 148 mm

• Fixed spout

• Aerator type: HONEYCOMB® - improved lime

protection | PCA® - constant flow rate regardless

of pressure variations | CACHÉ® - hidden aerator

without housing

• Aerator type: HONEYCOMB® - improved lime

protection | CASCADE® - aerated stream | CACHÉ®

- hidden aerator without housing

44882183

Chrome

EAN 4057304014796

Valid From: 01-04-2020

€ 296,00

NEW

• Fixed spout

• Aerator type: HONEYCOMB® - improved lime

protection | PCA® - constant flow rate regardless

of pressure variations | CACHÉ® - hidden aerator

without housing

44000100

EAN 4057304006661

€ 191,00

H

A

N

S

A

R

O

N

D

A

• Ø 40 mm ceramic cartridge for flow and tempera-

ture control

• Consisting of: Gasket sleeve for dry mortar-

lessconstruction|Mountingboxandcoversleeve
