172

Issue 01/2020

cross-series

HANSA | LIVING

02260100

Black

EAN 4015474606586

• Consisting of: Sleeve

02200100

EAN 4015474598287

• G1/2

Accessories: Raising kit, 45-80 mm, 59 905 576; Raising kit, 80-115 mm, 59 905 577

€ 81,70

HANSA

Other accessories

Concealed unit

Wall mounted for concealed unit,

DN20

• Body made of DZR brass

Installation depth: 10 - 80 mm

Flow-rate at 3 bar: 48 l/min

Hot water supply: max. +90°C

• G3/4

• Ceramic head part for flow control

Accessories: Raising kit, 80 mm, 59 910 424

HANSA

Other accessories

Wall mounted for concealed unit,

DN15

• Body made of DZR brass

Installation depth: 10 - 45 mm

Flow-rate at 3 bar: 30 l/min

Hot water supply: max. +90°C

€ 33,40

02210100

EAN 4015474598294

• G3/4

Accessories: Raising kit, 45-80 mm, 59 905 576; Raising kit, 80-115 mm, 59 905 577

€ 44,30

HANSA

Other accessories

Wall mounted for concealed unit,

DN20

• Body made of DZR brass

Installation depth: 10 - 45 mm

Flow-rate at 3 bar: 48 l/min

Hot water supply: max. +90°C

HANSALIVING

Shower accessories

Wall mounted, DN15

• protected against back-flow in domestic

use (according to DIN EN 1717)

Hot water supply: max. +90°C

– Wall connection elbow

• G1/2

Backflow prevention (EN1717): EB

51180183

Chrome

EAN 4057304007149

• Non-return valve(s)

• Consisting of: Soft edge rosette

€ 60,90

• Non-ceramic head part for flow control

• Non-ceramic head part for flow control
