194

Issue 01/2020

HANSAMIX

HANSA | HOME

H

A

N

S

A

M

I

X

HANSAMIX

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Rapid installation system

Flow-rate at 3 bar (with flow controller): 7.8 l/min

Eco-flow at 3 bar: 4.2 l/min

Hot water supply: max. +80°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Pop-up waste with draw-rod

• Flexible inlet pipes (G3/8)

01102283

Chrome

EAN 4015474271135

€ 159,00

DVGW: NW-6506BU0493, KIWA: K6116/06, ABP: P-IX 28487/IA

HANSAMIX XS

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Rapid installation system

Flow-rate at 3 bar (with flow controller): 7.8 l/min

Eco-flow at 3 bar: 4.2 l/min

Hot water supply: max. +80°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Flexible inlet pipes (G3/8)

• Ø 48 mm ceramic eco cartridge for flow and

0116 2283

Chrome

EAN 4015474271180

€ 144,00

temperature control

DVGW: NW-6506BU0493, KIWA: K6116/06, ABP: P-IX 28487/IA

HANSAMIX

Washbasin faucets

Single-lever |

Deck mounted (2 hole), DN15

• Body made of DZR brass

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +65°C

Pull-out hand spray

– Hand shower

– Shower hose (1250 mm)

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• (Ø 10 mm)

KIWA: K6116/06

01262183

Chrome

EAN 4015474271623

€ 203,00

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

• Projection: 127 mm

• Fixed spout

• Aerator type: HONEYCOMB® - improved lime

protection | PCA® - constant flow rate regardless

of pressure variations | Adjustable flow angle

• Without pop-up waste | Without draw-rod

opening

• Projection: 127 mm

• Fixed spout

• Aerator type: HONEYCOMB® - improved lime

protection | PCA® - constant flow rate regardless

of pressure variations

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

• Non-return valve(s)

• Consisting of: Round rosette | Sleeve | Operating

lever

• Aerator type: CASCADE® - aerated stream
