HANSA | HOME

HANSAPICO

46179103

Chrome

EAN 4057304011696

• Consisting of: Round rosette

5050 0100

50500100

EAN 4015474117990

Concealed shower thermostat HANSABLUEBOX

HANSAHOME

ture control

88619045

Chrome

EAN 4015474278981

€ 440,00

Issue 01/2020

285

ø170

ø56

40

14

64-94

Shower faucets

Trim Kit/Thermostatic |

Wall mounted for concealed unit

• Body made of DZR brass

• BLUECLICK for an easy, screwless trim

plate installation

• BLUETUNE alignment after installation

of +/– 3,5o

Flow-rate at 3 bar: 22.8 l/min

Hot water supply: max. +80°C

Diameter: 170 mm

• Temperature control handle

• Flow control handle

• Safety stop against scalding at 38°C

• Ceramic head part for flow control

• Thermostatic cartridge for automatic temperature

control

Accessories: Handle, for disinfection, 59 914 169

44 min.

14 min.

G1/2

HANSAPICO

Bath and shower faucets

Trim Kit/Single-lever |

Wall mounted for concealed unit

Hot water supply: max. +80°C

• Single operating lever/handle

• Hot/Cold symbols

ACS: 16 ACC NY 205

Required sales items

HANSAVARIO Installation technology

HANSAVARIO

Installation technology

Concealed unit |

Wall mounted, DN15

• Body made of DZR brass

Flow-rate at 3 bar: 16.8 l/min

Hot water supply: max. +90°C

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

€ 36,50

DVGW: DW-6509CS0197, ABP: P-IX 28852/IC, SVGW: 1805-6755, ACS: 16 ACC LY 695

Required sales items

HANSABLUEBOX Installation technology

HANSABLUEBOX Installation technology

8000 0000

8001 0000

• G1/2

• Ø 35 mm ceramic cartridge for flow and tempera-

• Non-return valve(s)

• Consisting of: Rosette plate frame | Round

rosette | Fastening of the function unit with

screws | Sleeve

• Without diverter

€ 57,30
