Concealed faucets

HANSAMATRIX Installation examples

Alternative components

Single-lever mixer with diverter

1

HANSADESIGNO

STYLE

trim kit

single-lever faucet

suitable for HANSAMATRIX

installation unit

4451 9583 chrome

with 2-way-diverter

HANSALIGNA

trim kit

single-lever faucet

suitable for HANSAMATRIX

installation unit

4455 9503 chrome

diverter shower/bath, with

2-way-diverter

HANSASTELA

trim kit

single-lever faucet

suitable for HANSAMATRIX

installation unit

4457 9503 chrome

diverter shower/bath, with

2-way-diverter

HANSARONDA

trim kit

single-lever faucet

suitable for HANSAMATRIX

installation unit

4459 9503 chrome

diverter shower/bath, with

2-way-diverter

HANSAMATRIX

concealed installation unit,

DN 15 (G 1/2)

single-lever faucet

4401 0100

suitable for trim kit

HANSAMATRIX 4.0

with 2-way-diverter

|�1.4.2020

Thermostat with shut-off and diverter

1

HANSALIVING

trim kit with function unit

thermostatic mixer,

DN 15 (G1/2)

suitable for HANSAMATRIX

installation unit

4453 9583 chrome

for 2 outlets, suitable for

HANSASIGNATUR, HANSALOFT,

HANSADESIGNO, HANSALIGNA,

HANSASTELA, HANSARONDA,

with 2-way-diverter/with

volume control

HANSAMATRIX

concealed installation unit,

DN 15 (G 1/2)

thermostatic mixer

4403 0100

for 2 outlets, with protection

against scalding, with 2-way-

diverter

2

3

HANSALIVING

wall bar set 1100 mm

4442 0100 chrome

HANSASTILO hand shower,

Silverjet

®

shower hose

1600 mm, chrome optic

HANSAFILL for distant positioned bathtub spout

HANSALIVING

shower set

Rosette soft edge - rounded

4443 0170 chrome*

HANSASTILO hand shower,

Silverjet

®

shower hose

1250 mm, chrome optic

* matching

HANSADESIGNO

STYLE

HANSADESIGNO

STYLE

bathtub spout, DN 15

5116 2180 chrome

also compatible with

HANSAMATRIX, square rosette,

75 x 75 mm additionally included,

Rosette soft edge - rounded, round

rosette,

Ø 75 mm additionally enclosed

projection: 195 mm

HANSALIGNA

bathtub spout, DN 15 (G 1/2)

0682 2102 chrome

also compatible with

HANSAMATRIX

projection: 180 mm

HANSASTELA

bathtub spout, DN 15 (G 1/2)

5782 2100 chrome

also compatible with

HANSAMATRIX

projection: 160 mm

HANSARONDA

bathtub spout, DN 15 (G 1/2)

0582 2172 chrome

also compatible with

HANSAMATRIX

projection: 180 mm

HANSA

trim kit

Pipe interrupter

4481 0000 chrome

also compatible with

HANSAMATRIX

HANSA

Pipe interrupter

concealed installation unit,

DN 15 (G 1/2)

4480 0000

available for 4481 0000 and

4482 0000

HANSAFILL

trim kit

0519 9000 chrome

HANSAFILL

tub filler and drain assembly

installation set

0516 0100

For HANSAFILL

replaces

4404 0100

from item

3

Issue 01/2020
