Concealed faucets

HANSAMATRIX Installation examples

Alternative components

Single-lever mixer with diverter

1

HANSADESIGNO

STYLE

trim kit

single-lever faucet

suitable for HANSAMATRIX

installation unit

4451 9583 chrome

with 2-way-diverter

HANSALIGNA

trim kit

single-lever faucet

suitable for HANSAMATRIX

installation unit

4455 9503 chrome

diverter shower/bath, with

2-way-diverter

HANSASTELA

trim kit

single-lever faucet

suitable for HANSAMATRIX

installation unit

4457 9503 chrome

diverter shower/bath, with

2-way-diverter

HANSARONDA

trim kit

single-lever faucet

suitable for HANSAMATRIX

installation unit

4459 9503 chrome

diverter shower/bath, with

2-way-diverter

HANSAMATRIX

concealed installation unit,

DN 15 (G 1/2)

single-lever faucet

4401 0100

suitable for trim kit

HANSAMATRIX 4.0

with 2-way-diverter

|�1.4.2020

Thermostat with shut-off and diverter

1

HANSALIVING

trim kit with function unit

thermostatic mixer,

DN 15 (G1/2)

suitable for HANSAMATRIX

installation unit

4453 9583 chrome

for 2 outlets, suitable for

HANSASIGNATUR, HANSALOFT,

HANSALIGNA, HANSASTELA,

HANSARONDA,

with 2-way-diverter/with

volume control

HANSAMATRIX

concealed installation unit,

DN 15 (G 1/2)

thermostatic mixer

4403 0100

for 2 outlets, with protection

against scalding, with 2-way-

diverter

2

3

HANSALIVING

wall bar set 1100 mm

4442 0100 chrome

HANSASTILO hand shower,

Silverjet

®

shower hose

1600 mm, chrome optic

HANSARONDA

bathtub spout, DN 15 (G 1/2)

0582 2172 chrome

also compatible with

HANSAMATRIX

projection: 180 mm

HANSADESIGNO STYLE

HANSAMATRIX

concealed installation unit,

DN 15 (G 1/2)

connection angle

4404 0100

multifix fastening system,

with gasket sleeve

HANSALIVING

shower set

Rosette soft edge - rounded

4443 0170 chrome*

HANSASTILO hand shower,

Silverjet

®

shower hose

1250 mm, chrome optic

* matching

HANSALOFT

bathtub spout, DN 15

5765 2100 chrome

also compatible with

HANSAMATRIX

projection: 197 mm

HANSADESIGNO

STYLE

bathtub spout, DN 15

5116 2180 chrome

also compatible with

HANSAMATRIX, square rosette,

75 x 75 mm additionally

included, Rosette soft edge -

rounded, round rosette,

Ø 75 mm additionally enclosed

projection: 195 mm

HANSALIGNA

bathtub spout, DN 15 (G 1/2)

0682 2102 chrome

also compatible with

HANSAMATRIX

projection: 180 mm

HANSASTELA

bathtub spout, DN 15 (G 1/2)

5782 2100 chrome

also compatible with

HANSAMATRIX

projection: 160 mm

Replaces item

3

Issue 01/2020
