354

Issue 01/2020

HANSA | LIVING

Touchless faucets

max

min

HANSADESIGNO STYLE

Washbasin faucets

Trim Kit/Touchless/External trans-

former |

Wall mounted for concealed unit ,

DN15

• Settings adjustable via magnetic key

• Rotating installation option

Flow-rate at 3 bar: 6.6 l/min

Hot water supply: max. +70°C

• Temperature control handle

• G1/2

• Thermostatic cartridge for automatic temperature

control

• Infrared sensor

• External control unit

• Power supply

• Consisting of: Square rosette

• Automatic flush frequency: off

(off/12/24/48/72 h)

– Automatic flush period: 30 s (10/30/60/120/18

0/240/300/600 s)

Required sales items

HANSAMATRIX Installation technology

HANSAMATRIX

Installation technology

Concealed unit/External transformer |

Wall mounted, DN 15

• Body made of DZR brass

• Multifix fastening system

• Rotating installation option

• Extension of the installation depth by

5 mm by fastening on the assembly rail;

protected against back-flow in domestic

use (according to DIN EN 1717)

Installation depth: 65 - 90 mm

Flow-rate at 3 bar: 21 l/min

Hot water supply: max. +70°C

• Limitation option for maximum temperature and

flow-rate

• Silencer(s) G1/2

• Thermostatic cartridge for automatic temperature

control

• Non-return valve(s)

• Litter filter(s)

4492 2010

Chrome

EAN 4057304006685

€ 369,00

T

o

u

c

h

l

e

s

s

f

a

u

c

e

t

s

H

A

N

S

A

|

L

I

V

I

N

G

Accessories: Assembling plate, 4405 0000; Assembling plate, 4405 0100

• Projection: 195 mm

• Fixed spout

• Aerator type: HONEYCOMB® - improved lime

protection | CACHÉ® - hidden aerator without

housing

• Max. flow period: 120 s (10/30/60/120/300 s)

• Operating voltage: 12 V

4409 0000

44090000

EAN 4015474277908

€ 470,00

• Pressure plug

• Connection cable: 10 m, 4 x 0.25 mm2

• Consisting of: Gasket sleeve for dry mortar-

less construction | Mounting box and cover

sleeve | Concealed electronics box

• Operating voltage: 12 V
