HANSA | LIVING
HANSALOFT
57762073
Chrome
EAN 4015474263420
Issue 01/2020
35
min
• G1/2
• Ø 35 mm ceramic cartridge for flow and tempera-
ture control
max
HANSALOFT
Bath and shower faucets
Trim Kit/Single-lever
Floor standing (1 hole), DN15
• Body made of DZR brass
• protected against back-flow in domestic
use (according to DIN EN 1717)
Flow-rate at 3 bar: 20.4 / 19.2 l/min
Hot water supply: max. +65°C
Pull operated diverter
Automatic reset
– Hand shower
– Shower holder
– Shower hose (1250 mm)
• Single operating lever/handle
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
• Ø 35 mm ceramic cartridge for flow and tempera-
ture control
Required sales items
HANSAVARIO Installation technology
HANSAVARIO
Installation technology
Concealed unit
Floor standing (1 hole), DN15
• Body made of DZR brass
Installation depth: 82 - 160 mm
Hot water supply: max. +90°C
• G1/2
• Rinsing plug
HANSALOFT
Bath and shower faucets
Trim Kit/Single-lever
Wall mounted for concealed unit
Hot water supply: max. +80°C
Push operated diverter
• Single operating lever/handle
• Hot/Cold symbols
Required sales items
HANSAVARIO Installation technology
HANSAVARIO
Installation technology
Concealed unit
Wall mounted for concealed unit,
DN15
• Body made of DZR brass
Installation depth: 30 - 65 mm
Flow-rate at 3 bar: 21.6 / 18 l/min
Hot water supply: max. +80°C
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
€ 2.032,00
H
A
N
S
A
L
O
F
T
• Non-return valve(s)
• Consisting of: Round rosette
• Projection: 197 mm
• Aerator type: HONEYCOMB® - improved lime
protection | CACHÉ® - hidden aerator without
housing
5328 0100
53280100
EAN 4015474186552
€ 417,00
• Pressure plug
• Consisting of: Mounting box and cover sleeve
50719003
Chrome
EAN 4057304011566
€ 68,70
• Limitation option for maximum temperature and
flow-rate
• Consisting of: Square rosette
5000 0900
50000900
EAN 4057304011726
€ 73,20
