Touchless faucets

HANSAELECTRA

80802120

Chrome

EAN 4057304008511

HANSAELECTRA

Washbasin faucets

€ 481,00

ø170

324

310

14

Trim Kit/Touchless/External

transformer |

Wall mounted for concealed unit

• BLUECLICK for an easy, screwless trim

plate installation

• Settings adjustable via magnetic key

Flow-rate at 3 bar (with flow controller): 4.8 l/min

Hot water supply: max. +70°C

• One inlet for cold or premixed water

• Litter filter(s)

• Autofocus infrared sensor

• Solenoid valve

• External control unit

• Light indicated function(s)

• Consisting of: Round rosette

• Without transformer

• Automatic flush frequency:

off (off/6/12/18/24/30/36/48/60/72 h)

– Automatic flush period: 30 s

(30/60/90/120/180/240/300/360/480/600 s)

Accessories: Transformer, 230/12 VDC 1A, 6499 0100; Connection cable, L=10000, 59 912 972

ABP: PA-IX 29285/IO

Required sales items

HANSA Fixing parts

HANSA Concealed unit

HANSABLUEBOX Installation technology

HANSAELECTRA

Washbasin faucets

Trim Kit/Touchless/External

transformer |

Wall mounted for concealed unit

• BLUECLICK for an easy, screwless trim

plate installation

• BLUESWITCH 2-way operated diverter

with volume control and stop function

• Settings adjustable via magnetic key

Flow-rate at 3 bar (with flow controller): 4.8 l/min

Hot water supply: max. +70°C

• Flow control handle

• Mixing valve for manual temperature control

• Non-return valve(s)

• Litter filter(s)

• Autofocus infrared sensor

• Solenoid valve

• External control unit

• Light indicated function(s)

• Consisting of: Round rosette

• Without transformer

59 912 972

6499 0100

8001 0000

80812111

Chrome

EAN 4057304008535

• Automatic flush frequency:

€ 573,00

• Projection: 310 mm

• Aerator type: CASCADE® - aerated stream |

PCA® - constant flow rate regardless of pressure

variations

• Max. flow period: 60 s

(10/30/60/90/120/150/180/210/240/300 s)

• Operating voltage: 12 V

ø170

260

245

40

14

5

8

5

8

ø

2

8

T

o

u

c

h

l

e

s

s

f

a

u

c

e

t

s

H

A

N

S

A

E

L

E

C

T

R

A

ø

2

8

Accessories: Transformer, 230/12 VDC 1A, 6499 0100; Connection cable, L=10000, 59 912 972

ABP: PA-IX 29284/IO

Required sales items

HANSA Fixing parts

HANSA Concealed unit

HANSABLUEBOX Installation technology

59 912 972

6499 0100

8001 0000

off (off/6/12/18/24/30/36/48/60/72 h)

– Automatic flush period: 30 s

(30/60/90/120/180/240/300/360/480/600 s)

• Projection: 245 mm

• Aerator type: CASCADE® - aerated stream |

PCA® - constant flow rate regardless of pressure

variations

• Max. flow period: 60 s

(10/30/60/90/120/150/180/210/240/300 s)

• Operating voltage: 12 V

Issue 01/2020

369
