Thermostatic faucets

HANSAUNITA

HANSAUNITA

282

150±15

G 1/2

200

Bath and shower faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 20.4 / 19.2 l/min

Hot water supply: max. +80°C

Pull operated diverter

Automatic reset

– Eco flow control

• Temperature control handle

• Flow control handle

• Eco feature for water flow

• Safety stop against scalding at 38°C

• The housing of the fittings conducts minimal

heat

• Eccentric coupling(s)

Backflow prevention (EN1717): EB

ABP: PA-IX 29492/IDB

Bath and shower faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 20.4 / 19.2 l/min

Hot water supply: max. +80°C

Pull operated diverter

Automatic reset

• Temperature control handle

• Flow control handle

• Eco feature for water flow

• Safety stop against scalding at 38°C

• The housing of the fittings conducts minimal

heat

• G3/4

Backflow prevention (EN1717): EB

• Ceramic head part for flow control

• Ceramic head part for flow control

• Thermostatic cartridge for automatic temperature

control

• Non-return valve(s)

• Litter filter(s)

• Projection: 180 mm

• Fixed spout

• Aerator type: CASCADE® - aerated stream

• Thermostatic cartridge for automatic temperature

control

• Non-return valve(s)

• Litter filter(s)

• Without couplings

• Projection: 157 mm

• Fixed spout

• Aerator type: CASCADE® - aerated stream

Issue 01/2020

385

HANSAUNITA

5837 2101

€ 237,00

Chrome

EAN 4015474277649

125

183

HANSAUNITA

5837 2001

€ 226,00

Chrome

EAN 4015474277656
