386

Issue 01/2020

HANSAUNITA

295

150±15

Thermostatic faucets

G 1/2

58

100

HANSAUNITA

Shower faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• Thermal disinfection

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 19.2 l/min

Eco-flow at 3 bar: 10.2 l/min

Hot water supply: max. +80°C

– Eco flow control

• Temperature control handle

• Flow control handle

• Eco feature for water flow

• Adjustable hot water stop (retrofittable)

• Safety stop against scalding at 38°C

• The housing of the fittings conducts minimal

heat

ABP: PA-IX 29504/IB, CSTB: 322-M1-19/1

HANSAUNITA

Shower faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 19.2 l/min

Hot water supply: max. +90°C

• Temperature control handle

• Flow control handle

• Eco feature for water flow

• Adjustable hot water stop (retrofittable)

• Safety stop against scalding at 38°C

• Ceramic head part for flow control

CSTB: 322-M1-19/1

58130101

Chrome

EAN 4015474253346

• Eccentric coupling(s) G1/2

€ 177,00

Backflow prevention (EN1717): EB

• Ceramic head part for flow control

• Thermostatic cartridge for automatic temperature

control

• Non-return valve(s)

• Litter filter(s)

58130001

Chrome

EAN 4015474255630

€ 163,00

T

h

e

r

m

o

s

t

a

t

i

c

f

a

u

c

e

t

s

3

2

G

1

/

2

•

•

•

•

Thermostatic cartridge for automatic temperature

control

Non-return valve(s)

Litter filter(s)

Without couplings
