HANSAPRISMA

5810 2101

€ 261,00

Chrome

HANSAPRISMA

EAN 4015474259294

5808 0101

€ 207,00

Chrome

EAN 4015474259225

HANSAPRISMA

Thermostatic faucets

HANSAPRISMA

Bath and shower faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• Thermal disinfection

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 22.2 / 19.2 l/min

Hot water supply: max. +90°C

Turn operated diverter

Integrated into flow control handle

• Temperature control handle

• Flow control handle

• Adjustable hot water stop (retrofittable)

• Safety stop against scalding at 38°C

• The housing of the fittings conducts minimal

heat

• Eccentric coupling(s) | Cover plate(s) | Silencer(s)

G1/2

ABP: PA-IX 29310/IIDB

Shower faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• Thermal disinfection

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 19.2 l/min

Hot water supply: max. +90°C

• Temperature control handle

• Flow control handle

• Eco feature for water flow

• Adjustable hot water stop (retrofittable)

• Safety stop against scalding at 38°C

• The housing of the fittings conducts minimal

heat

• Eccentric coupling(s) | Cover plate(s) | Silencer(s)

G1/2

DVGW: NW-6509CR0104, ABP: PA-IX 28485/IB

Backflow prevention (EN1717): EB

• Thermostatic cartridge for automatic temperature

control

• Non-return valve(s)

• Litter filter(s)

• Projection: 182 mm

• Aerator type: CASCADE® - aerated stream

Backflow prevention (EN1717): EB

•

•

•

•

•

Ceramic head part for flow control

Thermostatic cartridge for automatic temperature

control

Non-return valve(s)

Litter filter(s)

Solenoid valve

388

Issue 01/2020
