HANSAMEDIPRO
0171 2192
€ 190,00
Chrome
HANSAMEDIPRO
EAN 4015474267053
0161 2103
€ 174,00
HANSAMEDIPRO
Chrome
EAN 4015474266735
0162 2193
€ 163,00
Chrome
EAN 4015474266940
HANSAMEDIPRO
Health & Care
Washbasin faucets
Single-lever |
Deck mounted (1 hole), DN15
• Body made of DZR brass
• Surfaces in contact with drinking water
contain less than 0.3% lead
• Waterways without nickel coating
• Rapid installation system
• Safety control cartridge with operation
on one level
Flow-rate at 3 bar (with flow controller): 6 l/min
Hot water supply: max. +90°C
• Single operating lever/handle
• Long shape
• Safety feature for water temperature
• Hot/Cold symbols
• Copper inlet pipes (Ø10)
• Ø 35 mm ceramic cartridge for flow and tempera-
ture control
DVGW: NW-6506CR0028, ABP: P-IX 28471/IO
Washbasin faucets
Single-lever |
Deck mounted (1 hole), DN15
• Body made of DZR brass
• Surfaces in contact with drinking water
contain less than 0.3% lead
• Waterways without nickel coating
• Rapid installation system
Flow-rate at 3 bar: 12 l/min
Hot water supply: max. +80°C
• Single operating lever/handle
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
• Pop-up waste with draw-rod
• Copper inlet pipes (Ø10)
•
•
•
•
Without pop-up waste | Without draw-rod
opening
Projection: 120 mm
Fixed spout
Aerator type: HONEYCOMB® - improved lime
protection | Care® - for use in hospitals and other
care facilities | Laminar - crystal clear stream
DVGW: NW-6506CR0028, ABP: P-IX 28470/IA, ACS: 16
Washbasin faucets
Single-lever |
Deck mounted (1 hole), DN15
• Body made of DZR brass
• Surfaces in contact with drinking water
contain less than 0.3% lead
• Waterways without nickel coating
• Rapid installation system
Flow-rate at 3 bar: 12 l/min
Hot water supply: max. +80°C
• Single operating lever/handle
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
• Copper inlet pipes (Ø10)
• Ø 48 mm ceramic cartridge for flow and tempera-
•
•
•
•
Without pop-up waste | Without draw-rod
opening
Projection: 120 mm
Fixed spout
Aerator type: HONEYCOMB® - improved lime
protection | Care® - for use in hospitals and other
care facilities | Laminar - crystal clear stream
ACC NY 271
•
•
•
•
Ø 48 mm ceramic cartridge for flow and tempera-
ture control
Projection: 120 mm
Fixed spout
Aerator type: HONEYCOMB® - improved lime
protection | Care® - for use in hospitals and other
care facilities | Laminar - crystal clear stream
ACC NY 271
ture control
DVGW: NW-6506CR0028, ABP: P-IX 28470/IA, ACS: 16
446
Issue 01/2020
