Health & Care

HANSAMEDIPRO

HANSAMEDIPRO XS

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Surfaces in contact with drinking water

contain less than 0.3% lead

• Waterways without nickel coating

• Rapid installation system

Flow-rate at 3 bar: 12 l/min

Hot water supply: max. +80°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Pop-up waste with draw-rod

• Copper inlet pipes (Ø10)

•

•

•

•

Ø 48 mm ceramic cartridge for flow and tempera-

ture control

Projection: 120 mm

Fixed spout

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

ACC NY 271

0163 2103

€ 153,00

Chrome

EAN 4015474266452

DVGW: NW-6506CR0028, ABP: P-IX 28470/IA, ACS: 16

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Surfaces in contact with drinking water

contain less than 0.3% lead

• Waterways without nickel coating

• Rapid installation system

Flow-rate at 3 bar: 12 l/min

Hot water supply: max. +80°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Copper inlet pipes (Ø10)

• Ø 48 mm ceramic cartridge for flow and tempera-

•

•

•

•

Without pop-up waste | Without draw-rod

opening

Projection: 120 mm

Fixed spout

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

ACC NY 271

€ 141,00

ture control

DVGW: NW-6506CR0028, ABP: P-IX 28470/IA, ACS: 16

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Surfaces in contact with drinking water

contain less than 0.3% lead

• Waterways without nickel coating

Flow-rate at 3 bar (with flow controller): 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• One inlet for cold or premixed water

• Ceramic head part for flow control

• Without pop-up waste | Without draw-rod

opening

ABP: P-IX 28475/IA

•

•

•

Projection: 97 mm

Fixed spout

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

Issue 01/2020

447

HANSAMEDIPRO XS

HANSAMEDIPRO

0164 2103

Chrome

EAN 4015474266582

0198 2001

Chrome

€ 90,50

EAN 4015474267084
