Health & Care
Wall-mounted wash basin mixer
HANSA
HANSAMEDIPRO
59914579
€ 12,70
Issue 01/2020
451
265
150 10
246
161
3°
255
150 10
246
161
3°
Extension/connection cable, 2-pole;
connection cable 10 m
EAN 4057304009679
HANSAMEDIPRO
Washbasin faucets
Single-lever |
Wall mounted, DN15
• Body made of DZR brass
• Surfaces in contact with drinking water
contain less than 0.3% lead
• Waterways without nickel coating
• Rosette triple sealed
Flow-rate at 3 bar: 12 l/min
Hot water supply: max. +90°C
• Single operating lever/handle
• Long shape
• Loop shape
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
• Eccentric coupling(s) | Cover plate(s) | Integrated
02552205
Chrome
EAN 4015474267244
€ 276,00
9
3
9
4
9
3
9
4
6
5
6
5
H
e
a
l
t
h
&
C
a
r
e
H
A
N
S
A
M
E
D
I
P
R
O
shut-off valve(s)
DVGW: NW-6506CR0028, ABP: PA-IX 28473/IA, ACS: 16 ACC NY 271
HANSAMEDIPRO
Washbasin faucets
Single-lever |
Wall mounted, DN15
• Body made of DZR brass
• Surfaces in contact with drinking water
contain less than 0.3% lead
• Waterways without nickel coating
• Rosette triple sealed
Flow-rate at 3 bar: 12 l/min
Hot water supply: max. +90°C
• Single operating lever/handle
• Long shape
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
• Eccentric coupling(s) | Cover plate(s) | Integrated
02552206
Chrome
EAN 4015474267237
€ 276,00
shut-off valve(s)
DVGW: NW-6506CR0028, ABP: PA-IX 28473/IA, ACS: 16 ACC NY 271
• Ø 48 mm ceramic cartridge for flow and tempera-
ture control
• Projection: 246 mm
• Spout swivel range: 120° (0°)
• Swivel spout
• Lockable in the middle position
• Aerator type: HONEYCOMB® - improved lime
protection | Care® - for use in hospitals and other
care facilities | Laminar - crystal clear stream
• Ø 48 mm ceramic cartridge for flow and tempera-
ture control
• Projection: 246 mm
• Spout swivel range: 120° (0°)
• Swivel spout
• Lockable in the middle position
• Aerator type: HONEYCOMB® - improved lime
protection | Care® - for use in hospitals and other
care facilities | Laminar - crystal clear stream
