Issue 01/2020

457

HANSAMEDIPRO

Washbasin faucets

Thermostatic |

Wall mounted (2 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

• Rosette triple sealed

• Thermal disinfection

• Safety lock against scalding 38°C

(36°-44°)

Flow-rate at 3 bar: 12 l/min

Hot water supply: max. +80°C

• Temperature control handle

• Flow control handle

• Hot/Cold symbols

• Limitation option for maximum temperature

and flow-rate

• The housing of the fittings conducts

minimal heat

• Eccentric coupling(s) | Cover plate(s) | Integrated

shut-off valve(s)

Backflow prevention (EN1717): AA

• Ceramic head part for flow control

DVGW: NW-6509CR0103, ABP: PA-IX 28551/IA

HANSAMEDIPRO

Washbasin faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

• Rosette triple sealed

• Thermal disinfection

• Safety lock against scalding 38°C

(36°-44°)

Flow-rate at 3 bar: 12 l/min

Hot water supply: max. +80°C

• Temperature control handle

• Flow control handle

• Hot/Cold symbols

• Limitation option for maximum temperature

and flow-rate

• The housing of the fittings conducts

minimal heat

• Eccentric coupling(s) | Cover plate(s) | Integrated

shut-off valve(s)

Backflow prevention (EN1717): AA

• Ceramic head part for flow control

DVGW: NW-6509CR0103, ABP: PA-IX 28551/IA

€ 333,00

• Thermostatic cartridge for automatic temperature

control

• Non-return valve(s)

• Litter filter(s)

• Projection: 259 mm

• Spout swivel range: 120°

• Swivel spout

• Lockable in the middle position

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

08302281

Chrome

EAN 4057304013393

Valid From: 01-08-2019

€ 311,00

• Thermostatic cartridge for automatic temperature

control

• Non-return valve(s)

• Litter filter(s)

• Projection: 179

• Spout swivel range: 120°

• Swivel spout

• Lockable in the middle position

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream
