HANSAMEDICA

0104 2186

€ 178,00

Chrome

HANSAMEDICA

EAN 4015474271074

0108 2186

€ 176,00

HANSAMEDICA

Chrome

EAN 4015474271579

0119 2186

€ 236,00

Chrome

EAN 4015474271586

HANSAMEDICA

Health & Care

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

• Rapid installation system

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Chain holder with chain

• Copper inlet pipes (Ø10)

DVGW: NW-6506BU0493, ABP: P-IX 28486/IA

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

• Rapid installation system

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Copper inlet pipes (Ø10)

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

DVGW: NW-6506BU0493, ABP: P-IX 28486/IA

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Pop-up waste with draw-rod

• Copper inlet pipes (Ø10)

DVGW: NW-6506BU0493, ABP: P-IX 28488/IA

•

•

•

•

•

Ø 48 mm ceramic eco cartridge for flow and

temperature control

Without pop-up waste

Projection: 141 mm

Fixed spout

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

•

•

•

•

Without pop-up waste | Without draw-rod

opening

Projection: 141 mm

Fixed spout

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

•

•

•

•

•

Ø 48 mm ceramic eco cartridge for flow and

temperature control

Projection: 157 mm

Spout swivel range: 95°

Swivel spout

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

464

Issue 01/2020
