Health & Care

HANSAMEDICA

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Copper inlet pipes (Ø10)

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

DVGW: NW-6506BU0493, ABP: P-IX 28488/IA

Washbasin faucets

Single-lever |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Silencer(s)

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

DVGW: NW-6506BU0493, ABP: PA-IX 29302/IA

Washbasin faucets

Single-lever |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Integrated shut-off

valve(s) | Silencer(s)

DVGW: NW-6506BU0493, ABP: PA-IX 29302/IA

• Without pop-up waste | Without draw-rod

opening

• Projection: 157 mm

• Spout swivel range: 95°

• Swivel spout

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

Wall-mounted wash basin mixer

HANSAMEDICA

Chrome

EAN 4015474271203

0196 8176

€ 222,00

HANSAMEDICA

Chrome

EAN 4015474079410

• Projection: 160 mm

• Spout swivel range: 120°

• Swivel spout

• Lockable in the middle position

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

0196 8276

€ 249,00

Chrome

EAN 4015474080140

Issue 01/2020

465

HANSAMEDICA

0118 2186

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

• Projection: 171 mm

• Spout swivel range: 120°

• Swivel spout

• Lockable in the middle position

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

€ 219,00
