HANSAMEDICA

0194 8176

€ 225,00

Chrome

HANSAMEDICA

EAN 4015474078574

0194 8276

€ 251,00

HANSAMEDICA

Chrome

EAN 4015474078710

0169 2176

€ 239,00

Chrome

EAN 4015474080195

HANSAMEDICA

Health & Care

Washbasin faucets

Single-lever |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Silencer(s)

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

DVGW: NW-6506BU0493, ABP: PA-IX 29302/IA

Washbasin faucets

Single-lever |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Integrated shut-off

valve(s) | Silencer(s)

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

DVGW: NW-6506BU0493, ABP: PA-IX 29302/IA

Washbasin faucets

Single-lever |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Silencer(s)

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

DVGW: NW-6506BU0493, ABP: PA-IX 29302/IA

•

•

•

•

•

Projection: 235 mm

Spout swivel range: 120°

Swivel spout

Lockable in the middle position

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

•

•

•

•

•

Projection: 246 mm

Spout swivel range: 120°

Swivel spout

Lockable in the middle position

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

•

•

•

•

•

Projection: 300 mm

Spout swivel range: 120°

Swivel spout

Lockable in the middle position

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

466

Issue 01/2020
