Health & Care

HANSAMEDICA

HANSAMEDICA

Washbasin faucets

Single-lever |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Integrated shut-off

valve(s) | Silencer(s)

DVGW: NW-6506BU0493, ABP: PA-IX 29302/IA

Spout complete, 96 mm; suitable

for HANSAMEDICA, HANSACLINICA,

HANSATEMPRA; watercourse system

without nickel coating

96 mm

• Waterways without nickel coating

• Aerator type: CASCADE® - aerated stream

Accessories: Emptying valve, 59 912 483

Spout 145 mm;

suitable for HANSAMEDICA; HANSACL-

INICA until 2018; HANSATEMPRA;

watercourse system without nickel

coating

145 mm

• Waterways without nickel coating

• Spout swivel range: 120° (0°)

Accessories: Emptying valve, 59 912 483

Spout complete, 170mm; suitable

for HANSAMEDICA, HANSACLINICA,

HANSATEMPRA; watercourse system

without nickel coating

170 mm

• Waterways without nickel coating

• Aerator type: CASCADE® - aerated stream

Accessories: Emptying valve, 59 912 483

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

• Projection: 311 mm

• Spout swivel range: 120°

• Swivel spout

• Lockable in the middle position

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

• Aerator type: CASCADE® - aerated stream | Lami-

nar - crystal clear stream

HANSA

HANSA

HANSA

0169 2276

Chrome

EAN 4015474080225

59 910 419

Chrome

59 911 380

Chrome

59 911 183

Chrome

€ 92,70

EAN 4015474834347

€ 93,70

EAN 4015474945746

€ 93,70

EAN 4015474929784

Issue 01/2020

467

€ 267,00
