Health & Care

HANSACLINICA (NEW)

Issue 01/2020

477

HANSACLINICA

Washbasin faucets

Single-lever |

Wall mounted (2 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

• Rosette triple sealed

Flow-rate at 3 bar (with flow reducers): 10.2 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Loop shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Cover plate(s) | Integrated

shut-off valve(s) | Silencer(s) G1/2

Backflow prevention (EN1717): AA

HANSACLINICA

Washbasin faucets

Single-lever |

Wall mounted (2 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

• Rosette triple sealed

Flow-rate at 3 bar (with flow reducers): 10.2 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Cover plate(s) | Integrated

shut-off valve(s) | Silencer(s) G1/2

Backflow prevention (EN1717): AA

HANSACLINICA

Washbasin faucets

Single-lever |

Wall mounted (2 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

• Rosette triple sealed

Flow-rate at 3 bar (with flow reducers): 10.2 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Loop shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Cover plate(s) | Integrated

shut-off valve(s) | Silencer(s) G1/2

Backflow prevention (EN1717): AA

01546286

Chrome

EAN 4057304012617

Valid From: 01-09-2019

€ 244,00

NEW

• Ø 40 mm ceramic cartridge for flow and tempera-

ture control

• Litter filter(s)

• Projection: 377 mm

• Spout swivel range: 120° (60° / 0°)

• Swivel spout

• Swivel range limiting option

• Profile construction

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

01536283

Chrome

EAN 4057304013126

Valid From: 01-09-2019

€ 233,00

• Ø 40 mm ceramic cartridge for flow and tempera-

ture control

• Litter filter(s)

• Projection: 277 mm

• Spout swivel range: 120° (60° / 0°)

• Swivel spout

• Swivel range limiting option

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

H

e

a

l

t

h

&

C

a

r

e

H

A

N

S

A

C

L

I

N

I

C

A

(

n

e

w

)

01536286

Chrome

EAN 4057304010606

Valid From: 01-09-2019

€ 233,00

• Ø 40 mm ceramic cartridge for flow and tempera-

ture control

• Litter filter(s)

• Projection: 277 mm

• Spout swivel range: 120° (60° / 0°)

• Swivel spout

• Swivel range limiting option

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream
