HANSACLINICA

0150 2176

€ 171,00

Chrome

HANSACLINICA

EAN 4015474135710

0160 2173

€ 139,00

HANSACLINICA

Chrome

EAN 4015474135727

0160 2176

€ 159,00

Chrome

EAN 4015474135734

HANSACLINICA

Health & Care

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Loop shape

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Pop-up waste with draw-rod

ABP: P-IX 28417/IA

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Copper inlet pipes (Ø10)

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

ABP: P-IX 28417/IA

Washbasin faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Loop shape

• Long shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Copper inlet pipes (Ø10)

ABP: P-IX 28417/IA

Valid To: 30-06-2020

Replacements: 4501 2186

• Copper inlet pipes (Ø10)

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

• Projection: 153 mm

• Fixed spout

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

Valid To: 30-06-2020

Replacements: 4502 2183

• Without pop-up waste | Without draw-rod

opening

• Projection: 153 mm

• Fixed spout

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

Valid To: 30-06-2020

Replacements: 4502 2186

•

•

•

•

•

Ø 48 mm ceramic eco cartridge for flow and

temperature control

Without pop-up waste | Without draw-rod

opening

Projection: 153 mm

Fixed spout

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

484

Issue 01/2020
