HANSACLINICA

HANSACLINICA

0153 6276

EAN 4015474137264

0154 6173

€ 266,00

Chrome

€ 231,00

Chrome

HANSACLINICA

EAN 4015474135826

0154 6276

€ 279,00

Chrome

HANSA

EAN 4015474137295

59 912 483

€ 24,70

EAN 4015474071278

HANSACLINICA

Health & Care

Washbasin faucets

Single-lever |

Wall mounted (2 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Loop shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Cover plate(s) | Integrated

shut-off valve(s) | Silencer(s)

ABP: PA-IX 28892/IZ

Washbasin faucets

Single-lever |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Silencer(s)

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

ABP: PA-IX 28892/IZ

Washbasin faucets

Single-lever |

Wall mounted (2 hole), DN15

• Body made of DZR brass

• Waterways without nickel coating

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Long shape

• Loop shape

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Cover plate(s) | Integrated

shut-off valve(s) | Silencer(s)

ABP: PA-IX 28892/IZ

Retrofit set for spout draining

• Aerator type: CASCADE® - aerated stream

Valid To: 30-06-2020

Replacements: 0153 6286

• Ø 48 mm ceramic eco cartridge for flow and

temperature control

• Projection: 226 mm

• Spout swivel range: 120°

• Swivel spout

• Lockable in the middle position

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

Valid To: 30-06-2020

Replacements: 0154 6283

• Projection: 280 mm

• Spout swivel range: 120°

• Swivel spout

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

Valid To: 30-06-2020

Replacements: 0154 6286

•

•

•

•

•

•

Ø 48 mm ceramic eco cartridge for flow and

temperature control

Projection: 291 mm

Spout swivel range: 120°

Swivel spout

Lockable in the middle position

Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

486

Issue 01/2020
