HANSATEMPRA

0838 2202

€ 538,00

Chrome

HANSATEMPRA

EAN 4015474658646

0838 2292

€ 551,00

HANSATEMPRA

Chrome

EAN 4015474053939

0838 2212

€ 528,00

Chrome

EAN 4015474257528

Health & Care – Special thermostatic mixers

Washbasin faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

• Thermal disinfection

Flow-rate at 3 bar: 12 l/min

Hot water supply: max. +90°C

• Temperature control handle

• Flow control handle

• Long shape

• Limitation option for maximum temperature

and flow-rate

• Adjustable hot water stop (retrofittable)

• Safety stop against scalding at 38°C

• Eccentric coupling(s) | Integrated shut-off valve(s)

Backflow prevention (EN1717): AA

• Ceramic head part for flow control

ABP: PA-IX 29306/IA

Washbasin faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

• Thermal disinfection

Flow-rate at 3 bar: 12 l/min

Hot water supply: max. +90°C

• Temperature control handle

• Flow control handle

• Long shape

• Limitation option for maximum temperature

and flow-rate

• Adjustable hot water stop (retrofittable)

• Safety stop against scalding at 38°C

• Eccentric coupling(s) | Integrated shut-off valve(s)

G1/2

Backflow prevention (EN1717): AA

• Ceramic head part for flow control

ABP: PA-IX 29306/IA

Washbasin faucets

Thermostatic |

Wall mounted, DN15

• Body made of DZR brass

• Waterways without nickel coating

• Thermal disinfection

Flow-rate at 3 bar: 12 l/min

Hot water supply: max. +90°C

• Temperature control handle

• Flow control handle

• Limitation option for maximum temperature

and flow-rate

• Adjustable hot water stop (retrofittable)

• Safety stop against scalding at 38°C

• Eccentric coupling(s) | Integrated shut-off valve(s)

G1/2

Backflow prevention (EN1717): AA

• Ceramic head part for flow control

ABP: PA-IX 29306/IA

•

•

•

•

•

•

•

•

•

Thermostatic cartridge for automatic temperature

control

Non-return valve(s)

Litter filter(s)

Projection: 245 mm

Spout swivel range: 120°

Swivel spout

Lockable in the middle position

Casted construction

Aerator type: CASCADE® - aerated stream

•

•

•

•

•

•

•

•

•

•

Thermostatic cartridge for automatic temperature

control

Non-return valve(s)

Litter filter(s)

Projection: 245 mm

Spout swivel range: 120°

Swivel spout

Self-draining model

Lockable in the middle position

Casted construction

Aerator type: CASCADE® - aerated stream

•

•

•

•

•

•

•

•

•

Thermostatic cartridge for automatic temperature

control

Non-return valve(s)

Litter filter(s)

Projection: 245 mm

Spout swivel range: 120°

Swivel spout

Lockable in the middle position

Casted construction

Aerator type: CASCADE® - aerated stream

498

Issue 01/2020
