Maintenance and renovation

Multi-way/Concealed valves

Other accessories

Concealed unit |

Wall mounted for concealed unit,

DN20

• Body made of DZR brass

Installation depth: 10 - 80 mm

Flow-rate at 3 bar: 48 l/min

Hot water supply: max. +90°C

• G3/4

• Ceramic head part for flow control

Accessories: Raising kit, 80 mm, 59 910 424

Extension set 80 mm for concealed

valves DN 15 and DN 20; (G 1/2 and

G3/4)(15mm;18mmand22mm);

suitable for concealed valves item

no. 0225, 0226, 0235, 0236, 0237

and 0295

Other accessories

Wall mounted for concealed unit,

DN15

• Body made of DZR brass

Installation depth: 10 - 45 mm

Flow-rate at 3 bar: 30 l/min

Hot water supply: max. +90°C

• G1/2

Accessories: Raising kit, 45-80 mm, 59 905 576; Raising kit, 80-115 mm, 59 905 577

Other accessories

Wall mounted for concealed unit,

DN20

• Body made of DZR brass

Installation depth: 10 - 45 mm

Flow-rate at 3 bar: 48 l/min

Hot water supply: max. +90°C

• G3/4

Accessories: Raising kit, 45-80 mm, 59 905 576; Raising kit, 80-115 mm, 59 905 577

Issue 01/2020

523

HANSA

HANSA

0226 0100

EAN 4015474606586

• Consisting of: Sleeve

59 910 424

€ 81,70

Black

€ 22,40

HANSA

HANSA

EAN 4015474834736

0220 0100

EAN 4015474598287

• Non-ceramic head part for flow control

0221 0100

€ 33,40

€ 44,30

EAN 4015474598294

• Non-ceramic head part for flow control
