HANSA | HOME Kitchen faucets

HANSAMIX

01392183

Chrome

EAN 4015474276666

Issue 01/2020

555

HANSAMIX

Kitchen faucets

Single-lever |

Deck mounted (1 hole), DN15

• Body made of DZR brass

• Surfaces in contact with drinking water

contain less than 0.3% lead

• Waterways without nickel coating

• protected against back-flow in domestic

use (according to DIN EN 1717)

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

– Shower hose (1400 mm)

2 shower sprays

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Copper inlet pipes

• Ø 48 mm ceramic cartridge for flow and tempera-

ture control

HANSAMIX

Washbasin faucets

Single-lever |

Wall mounted, DN15

• Body made of DZR brass

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Silencer(s)

• Ø 48 mm ceramic eco cartridge for flow and

€ 450,00

temperature control

DVGW: NW-6506BU0493, KIWA: K6116/06, ABP: PA-IX 29302/IA

HANSAMIX

Washbasin faucets

Single-lever |

Wall mounted, DN15

• Body made of DZR brass

Flow-rate at 3 bar: 12 l/min

Eco-flow at 3 bar: 6 l/min

Hot water supply: max. +90°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Eccentric coupling(s) | Integrated shut-off

valve(s) | Silencer(s)

• Ø 48 mm ceramic eco cartridge for flow and

01692283

Chrome

EAN 4015474271364

€ 231,00

temperature control

DVGW: NW-6506BU0493, KIWA: K6116/06, ABP: PA-IX 29302/IA

• Non-return valve(s)

• Projection: 235 mm

• Spout swivel range: 140°

• Swivel spout

• Pull-out model

• Aerator type: CASCADE® - aerated stream

• Dishwasher valve type: Mechanic stop valve for

external equipment

01692183

Chrome

EAN 4015474271357

€ 205,00

• Projection: 300 mm

• Spout swivel range: 120° (0°)

• Swivel spout

• Casted construction

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream

• Projection: 311 mm

• Spout swivel range: 120° (0°)

• Swivel spout

• Casted construction

• Aerator type: HONEYCOMB® - improved lime

protection | Care® - for use in hospitals and other

care facilities | Laminar - crystal clear stream
