HANSA | LIVING

HANSADESIGNO STYLE

Bidet

max

min

HANSAMATRIX

Installation technology

Concealed unit/External transformer

Wall mounted, DN15

• Body made of DZR brass

• Multifix fastening system

• Rotating installation option

• Extension of the installation depth by

5 mm by fastening on the assembly rail;

protected against back-flow in domestic

use (according to DIN EN 1717)

Installation depth: 65 - 90 mm

Flow-rate at 3 bar: 21 l/min

Hot water supply: max. +70°C

• Limitation option for maximum temperature and

flow-rate

• Silencer(s) G1/2

• Thermostatic cartridge for automatic temperature

control

• Non-return valve(s)

• Litter filter(s)

44090000

EAN 4015474277908

€ 470,00

Accessories: Assembling plate, 4405 0000; Assembling plate, 4405 0100

• Pressure plug

• Connection cable: 10 m, 4 x 0.25 mm2

• Consisting of: Gasket sleeve for dry mortar-

less construction | Mounting box and cover

sleeve | Concealed electronics box

• Operating voltage: 12 V

3

9

6

1

6

9

4

-

4

0

4

3

8

4

-

4

0

3

5

-

5

0

1

2

0

1

3

3

9

8

3

5

-

4

5

9

7

H

A

N

S

A

D

E

S

I

G

N

O

S

T

Y

L

E

Issue 01/2020

61

48.5

59

ø46

ø35

142

119

ø33.5

ø63

G1 1/4

G1 1/4

G 3/8

141

117

85

max. 180

G3/8

• Projection: 119 mm

• Fixed spout

• Aerator type: HONEYCOMB® - improved lime

protection | PCA® - constant flow rate regardless

of pressure variations | CACHÉ® - hidden aerator

without housing | Ball joint

ø63

HANSADESIGNO STYLE

Bidet faucets

Single-lever, side operated

Deck mounted (1 hole), DN15

• 3S-installation system for safe and

simple mounting

Flow-rate at 3 bar (with flow controller): 6 l/min

Hot water supply: max. +80°C

• Single operating lever/handle

• Hot/Cold symbols

• Pop-up waste with draw-rod

• Flexible inlet pipes (G3/8)

• Ø 25 mm ceramic cartridge for flow and tempera-

ture control

ABP: P-IX (Certification requested)

HANSADESIGNO STYLE

Bidet faucets

Single-lever

Deck mounted (1 hole), DN15

• 3S-installation system for safe and

simple mounting

Flow-rate at 3 bar (with flow controller): 6 l/min

Hot water supply: max. +80°C

• Single operating lever/handle

• Hot/Cold symbols

• Limitation option for maximum temperature and

flow-rate

• Adjustable hot water stop (retrofittable)

• Pop-up waste with draw-rod

• Flexible inlet pipes (G3/8)

5198 3283

Chrome

EAN 4057304007224

€ 305,00

ABP: P-IX (Certification requested), ACS: 16 ACC NY 205

51733283

Chrome

EAN 4057304006715

€ 263,00

• Ø 40 mm ceramic cartridge for flow and tempera-

ture control

• Projection: 117 mm

• Fixed spout

• Aerator type: HONEYCOMB® - improved lime

protection | PCA® - constant flow rate regardless

of pressure variations | CACHÉ® - hidden aerator

without housing | Ball joint
